function

NC / NO

pressure range

0-16 / 0-40 bar
A → B max. 40 bar
B → A max. 16 bar
A → C max. 40 bar
C → A max. 40 bar

KV value

11,2 m3/h

media

gaseous? liquid? highly viscous? gelatinous? contaminated?

switching cycles

130 1/min

switching time

opening 130 ms
closing 130 ms

media temperature

DC -20 °C — +80 °C
AC -20 °C — +80 °C

ambient temperature

DC -20 °C — +80 °C
AC -20 °C — +80 °C

weight

MK 9,2 kg
FK 12,0 kg

nominal voltage

Un 24 V DC +5% / -10%
Un 230 V 40-60 Hz AC +5% / -10%

actuation

DC direct-current magnet
AC direct-current magnet with integrated rectifier

insulation rating

H 180 °C

protection

IP65

energized duty rating

ED 100%

connection

plug acc. DIN EN 175301-803, form A, 4 positions x 90°, wire diameter 6-8 mm
M12x1 connector acc. DESINA / VDMA
