BESTACE微差壓變送器761系列產品參數
Specifications | |||
Performance Data | Standard | Optional | Optional |
Accuracy* (at room temp) | ± 1.0%FS | ± 0.4%FS | ±0.25%FS |
Non-Linearity (BFSL) | ± 0.97%FS | ±0.33%FS | ± 0.20%FS |
Hysteresis | ±0.20%FS | ±0.20%FS | ±0.10%FS |
Hysteresis | ±0.20%FS | ±0.20%FS | ±0.10%FS |
Thermal Effects | |||
Compensated Range | 0t170°F(-18to 77℃) | ||
Zero/Span Shift | <0.028%FS/°F(<0.05%FS/℃） | ||
Maximum Line | 15PSI(100kPa) | ||
Pressure | 15PSI(100kPa) in Positive or Negative Direction for all ranges. | ||
Overpressure | ±0.1%FS | ||
Position Effect | Each unit is calibrated in the vertical position. For best accuracy, adjust zero of the unit if it is mounted in other position. It is not necessary to adjust the sensitivity. | ||
RSS of Non-Linearity, Hysteresis, and Non-Repeatability. | |||
BESTACE微差壓變送器761系列產品介紹
Model 761 series are low range differential pressure transducers and transmitters. It features a flame retardant plastic enclosure with a metal backing. The unique design makes it can be used at outdoor environment and with easy access to zero and sensitivity adjustments.
The pressure range covers from 0.1"WC to 100"WC， unidirectional or bidirectional. The output can be 3- -wire 0 to 5V, 0 to 10V, or 2-wire 4 to 20 mA, fully protected against short circuit and incorrect wiring. In the voltage version, the output can go down to true zero. The units are temperature compensated. The accuracy can be 1.0%, 0.4% or 0.25% at room temperature.
The patented stainless steel sensor provides good corrosion resistance, excellent performance and long term stability.
Our unique production setup can also make special pressure range (e.g. -0.5"WC to +3.5" WC) to meet special applications.
761系列是低量程差壓變送器和變送器。 它具有帶金屬背襯的阻燃塑料外殼。 獨特的設計使其可以在室外環境中使用，并且易于進行調零和靈敏度調整。
壓力范圍從0.1“ WC到100” WC，單向或雙向。 輸出可以是3線制0到5V，0到10V或2線制4到20 mA，完全可以防止短路和錯誤接線。 在電壓版本中，輸出可以下降到真正的零。 單位是溫度補償?shù)摹?在室溫下，精度可以是1.0％，0.4％或0.25％。
獲得專利的不銹鋼傳感器具有良好的耐腐蝕性，出色的性能和長期穩定性。
獨特的生產設置還可設定特殊的壓力范圍（例如-0.5“ WC到+3.5” WC），以滿足特殊應用。
BESTACE微差壓變送器761系列其他常見型號：
BESTACE 761-TT-42A
BESTACE 761-25-41A
BESTACE 761-19-11A
BESTACE 761-19-41B
BESTACE 761-23-11A
BESTACE 761-11-41A
BESTACE 761-19-41A
BESTACE 761-16-41A
BESTACE Pressure Transducer NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于BESTACE微差壓變送器761-TT-42A的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for BESTACE products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website: jjxdch.cn.
BESTACE微差壓變送器761系列761-TT-42A產品參數
