ROSS梭閥1968D3003技術參數
Valve Type | Shuttle Valve |
Series | 19 |
Application | High Flow |
Actuation | Pneumatic |
Function | 2/2 |
Thread Type | NPT |
Construction | Poppet |
Mounting | Inline |
Ambient Temperature | -40 to 175 F (-40 to 80 C) |
Media Temperature | -40 to 175 F (-40 to 80 C) |
Fluid Media | Filtered Air |
Operating Pressure | 5 to 150 psig (0.3 to 10 bar) |
Length | 2.64 in (67 mm) |
Width | 1.25 in (32 mm) |
Height | 2.13 in (54 mm) |
Weight | 0.8 lb (0.4 kg) |
Valve Body Material | Cast Aluminum |
Inlet Pipe Size | 3/8" |
Outlet Pipe Size | 3/8" |
Avg Cv | 3 |
ROSS梭閥19系列其他常用型號：
ROSS 1968A2920
ROSS 1968A2921
ROSS 1968B2910
ROSS 1968D1005
ROSS 1968D2001
ROSS 1968D2003
ROSS 1968D2005
ROSS 1968D3001
ROSS 1968D3003
ROSS 1968D4001
ROSS D1968D1005
ROSS D1968D2001
ROSS D1968D2003
ROSS D1968D2005
ROSS D1968D3001
ROSS valve NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于ROSS梭閥1968D3003的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for ROSS products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:jjxdch.cn.
