CANTONI電機3SIEK160L-4技術參數
Efficiency class: | IE3 |
Size: | 160 |
Number of poles: | 4 |
Start: | direct start or Y / ? |
Insulation class: | F |
Frequency converter supply: | yes |
Design: | IMB3 / B5 / B35 / B14 |
Cooling type: | IC411 |
Weight (IMB3) [kg]: | 154 |
Moment of Inertia [kgm2]: | 0.104 |
Direction of rotation: | CW / CCW |
Degree of protection: | IP55 |
Sound pressure level [dB]: | 61 |
Sound power level [dB]: | 74 |
Terminal box position: | above |
Rotation possibility of the terminal box: | yes |
Bearing AS: | 63092Z |
Bearing BS: | 63092Z |
Bearing lubrication: | on request |
Housing material: | cast iron |
Base material: | cast iron |
End shield material: | cast iron |
Painting: | RAL5010 |
Climatic version: | N |
CANTONI電機3SIE系列介紹
IE3 電機的優點是振動和噪音水平低、耐用、易于維護和軸承壽命長。 由于這些優勢，IE3 電機可用于許多工業領域的泵、通風機、輸送機等應用。 三相感應電機還可用于：操作機器（車、磨、銑、鉆、鏜、刨機等）、起重機、通風系統、攪拌機、洗衣機、泵、輸送機等。
Advantages of IE3 motors are low vibration and noise level, durability, easy maintenance and long bearings life. Thanks to these advantages IE3 motors are used for applications like pumps, ventilators, conveyors in many industrial sectors. 3 phase induction motors can be used also in: operational machines (turning, grinding, milling, drilling, boring, planning machines, etc.), cranes, ventilation systems, mixers, washing machines, pumps, conveyors, etc.
CANTONI電機3SIE系列其他常用型號：
CANTONI 3SIEK100L-2,6
CANTONI 3SIEK100L-4A,4B
CANTONI 3SIEK112M-2,6
CANTONI 3SIEK112M-4
CANTONI 3SIEK132S
CANTONI 3SIEK132M
CANTONI 3SIEK160M
CANTONI 3SIEK160L
CANTONI 3SIEK180M-2,4
CANTONI 3SIEK180L-4,6
CANTONI 3SIEK160M-4
CANTONI 3SIEK160L-4
CANTONI motor NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于CANTONI電機3SIEK160L-4的疑問，請隨時與我們電聯，（021-3100 6702），我們將盡全力解決您的問題。
If you have any question for CANTONI products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website: jjxdch.cn.
