RADICON減速機M系列技術參數
PRODUCT OPTIONS | |
Unit Sizes | 01, 02, 03, 04, 05, 06, 07, 08, 09, 10, 13, 14, 16 |
Types | Inline unit: Double, Triple, Quadruple and Quintupple reduction |
Input Power | Up to 150 HP (160 kW) |
Output Torque | Up to 183,000 lb.in (20,700 Nm) |
Gear Ratios | 3.6/1 to 200/1 up to Triple reduction and up to 10,000/1 in combined unit |
Motor Sizes | NEMA Frames from 56 to 440, IEC Frame 56 to 315 |
RADICON減速機M系列介紹
M 系列齒輪馬達可滿足大多數驅動要求，最高可達 214HP，最大輸出扭矩為 177,000 lb.in。
它充分利用了多年積累的設計專業知識，并使用了高品質的材料和組件。
最終結果是一系列減速和齒輪馬達，具有高承載能力、高效率、安靜運行和可靠性。這些裝置由一系列模塊化套件制造和組裝，以方便分銷商，從而最大限度地減少庫存并使產品隨時可用。
可提供法蘭或腳架安裝的雙、三、四和五倍減速裝置?？商峁╇妱?dòng)、電機就緒（接受客戶自己的 NEMA/IEC 電機）或帶鍵控輸入軸的減速器。
The Series M geared motor range meets most drive requirements up to 214HP with a maximum output torque of 177,000 lb.in.
It takes advantage of being developed from many years of accumulated design expertise, together with the use of high quality materials and components.
The end result is a series of speed reducing and geared motors offering high load carrying capacity, high efficiency, quiet running and reliability. These units are manufactured and assembled from a family of modular kits for distributor friendliness thereby minimizing inventory and making the product readily available.
Can be supplied as double, triple, quadruple and quintuple reduction units in flange or foot mount execution. Available as motorised, motor ready (to accept clients own NEMA/ IEC motor) or as a reducer with a keyed input shaft.
RADICON減速機M系列其他常用型號：
RADICON M02225.0BGCC1
RADICON M02225.6BANX
RADICON M02225.0BANT
RADICON M02225.0BGCC1D1.5A
RADICON M02225.0BGCC1
RADICON M01225.0BGCC1D15A
RADICON M02225.OBMCC1D1.5A
RADICON M02225.OBMCC1D1.5A-C
RADICON Motor NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于RADICON減速機M02225.OBMCC1D1.5A-C的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for RADICON products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website: jjxdch.cn.
RADICON減速機M系列M02225.OBMCC1D1.5A-C介紹
