EBARA離心泵CDX（L）系列產品參數
PUMP | Type of liquid | Clean water |
Liquid Handled | Temperature [°C] | min. -5 |
Maximum working pressure [MPa] | 0.8 | |
Construction | Impeller | Closed centrifugal type |
Pipe Connection | Suction [inch] | from G1"? to G1"? UNI ISO 228-1 |
Material | Casing | EN 1.4301 (AISI 304) - (AISI 316L only for “L” version) |
Applicable standard of test | ISO 9906:2012 - Grade 3B | |
EBARA離心泵CDX（L）系列產品介紹及選型
CDX（L）是帶有徑向葉輪的表面離心電動泵，其液壓系統完全采用AISI 304或AISI 316（L型）制成，其部件通過液壓成型工藝獲得，從而確保了強度，液壓效率和可靠性。
CDX（L）模型適用于從家庭增壓到小型灌溉，從水處理廠到蒸發塔的各種用途；因此通常用于處理清潔水。
標準機械密封由陶瓷/碳/丁腈橡膠制成，但有幾種特殊的密封可供選擇。
?液體溫度：-5°C÷+ 60°C（對于H，HS，HW和HSW版本，從-15°C到+ 110°C）
?總揚程從36.8到12.5 m
?流速1.2至15立方米/小時
?水力效率指數MEI> 0.4
?0.75kW起的IE3高效電機
CDX(L) are surface centrifugal electric pumps with radial impeller, with hydraulics completely in molded AISI 304 or AISI 316 (version L), whose components are obtained through the hydroforming process, which guarantees strength, hydraulic efficiency and reliability.
CDX(L) model is suitable for different uses ranging from domestic pressurisation to small irrigation, from water treatment plants to evaporative towers; therefore for handling clean water in general.
The standard mechanical seal is made of Ceramic/Carbon/NBR, but several special seals are available.
? Liquid temperature:-5°C ÷ +60°C (from -15°C to +110°C for H,HS, HW and HSW versions)
? Total head from 36.8 to 12.5 m
? Flow rate 1.2 to 15 m3/h
? Hydraulic efficiency index MEI > 0.4
? IE3 high efficiency motors starting from 0.75kW
EBARA離心泵CDXM系列其他常見型號：
EBARA CDXM70/05
EBARA CDXM70/07
EBARA CDXM90/10
EBARA CDXM120/07
EBARA CDXM120/20
EBARA CDXM200/12
EBARA CDXM200/20
EBARA CDXM/A90/10
EBARA Centrifugal pump NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于EBARA離心泵CDXM/A90/10的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for EBARA products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:jjxdch.cn.
EBARA離心泵CDX系列 CDXM/A90/10產品參數
