ROTECH限位開關PF3NVFAZ0技術規格
TECHNICAL DATA | |
Type: | SC3,5-N0, slot type NAMUR,Normally closed contact |
Depth of immersion: | 5 ... 7 mm |
Nominal voltage: | 8 V DC |
Operating current: | 5 ... 25 V DC |
Current consumpt.: | >= 3 mA, inactive |
Temperature: | -25 ... +85°C |
Switch. frequency: | 0 ... 3000 Hz |
Signal: | LED, yellow |
Housing: | Vestamid, black Cover with vision panel |
Sealing: | EPDM |
Ingress protection: | IP67 (Sensor) |
Switching precision: | <1.5° |
System connection: | Cable gland M20x1,5 |
Clamps: | Screw clamps up to 1,5 mm2 |
ROTECH限位開關PF3NVFAZ0介紹
ROTECH限位開關其他常用型號：
ROTECH PF3NVFAZ0
ROTECH PF818MVAZ
ROTECH PF3NVFAZ0
ROTECH PF211SVFAZ
ROTECH PF3NVAZ0
ROTECH PFF25NVFAZ0
ROTECH Limit switch NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于ROTECH限位開關PF3NVFAZ0的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for ROTECH products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website: jjxdch.cn.
ROTECH限位開關PF3NVFAZ0技術參數
