Contact material/contact gap

AgSnO2 /0.5 mm

Spacing of control connections/contact

6 mm

Test voltage control connections/contact

4000 V

Rated switching capacity

10 A/250 V AC

230 V LED lamps

up to 200 W
I on ≤ 120 A/5 ms

Incandescent lamp and halogen lamp load 230 V, I on ≤ 70 A/10 ms

2000 W

Fluorescent lamp load with KVG in lead-lag circuit or non compensated

1000 VA

Fluorescent lamp load with KVG shunt-compensated or with EVG

500 VA

Compact fl uorescent lamps with EVG and energy saving lamps ESL

15x7 W
10x20 W

Max. switching current DC1: 12 V/24 V DC

8 A

Life at rated load, cos  = 1 for incandescent lamps 1000 W at 100/h

> 10 5

Life at rated load, cos  = 0,6 at 100/h

> 4x10 4

Maximum conductor cross-section (3-fold terminal)

6 mm2 (4 mm2)

Two conductors of same cross-section (3-fold terminal)

2.5 mm2 (1.5 mm2)

Screw head

slotted/crosshead, pozidriv

Type of enclosure/terminals

IP50/IP20

Electronics

Time on

1

Max./min. temperature at mounting location

+50°C/-20°C

Temperature dependence

< 0.2% per oC

Repeat accuracy at 25oC

±0.1%

Stored energy time in the event of power failure (then total reset)

0.2 seconds

Standby loss (active power) 230 V

0.4-0.6 W

Control current universal control voltage 8/12/24/230 V (<10 s) ± 20%

0.05/0.1/ 0.2/1 mA

Max. parallel capacitance (approx. length) of the control leads at 230 V AC

0.2 μF (600 m)
