OKEEFE CONTROLS接頭BW-40-SS技術規格
Specifications | |
Orifice Diameter | 0.04 in |
Material | 303 SS |
Nominal Orifice Size | 40 |
CV | 0.036 |
Orifice Diameter Accuracy | ±0.0005 in |
Maximum Operating Pressure | 100 psig |
Width Across Flats (Hex) | 7/16 in |
Total Length | 0.880 in |
Air Flow at Vacuum, Choked Flow - Standard Cu. Ft. Per Hour (SCFH)_Sapphire | 1/8 |
Connection A | 1/8" NPT Male |
Connection B | 1/8" ID Barb |
Screened | None |
OKEEFE CONTROLS接頭B系列介紹
采用一體式固體金屬結構。 孔口經過精確加工，徹底清潔并進行了嚴格的標準流量測試。 孔徑范圍為.004“至.063”。特殊尺寸可以定做。
One-piece construction of solid metal is employed. Orifices are accurately machined, thoroughly cleaned, and flow tested to exacting standards. Sizes range from .004" to .063" orifice diameter. Special sizes can be made to order.
