ABB控制器2CDG110215R0011技術參數
Technical | |
Data Sheet, Technical Information: | 2CDC508217D0211 |
Special Functions: | Valve Protection |
Voltage Range: | 0 ... 10 V DC |
Maximum Switching Current: | 16 A |
Power Loss: | 3 W |
Number of Outputs: | 4 |
Number of Digital Inputs: | 4 |
Compatible Bus Systems: | KNX (TP) |
Manipulated Variable: | Continious |
Product Range: | KNX |
Mounting Type: | DIN-Rail |
Manual Operation: | Yes |
Color: | light grey |
Number of Batteries: | 0 |
Application Function: | Room Climate Control |
Environmental | |
Degree of Protection: | IP20 |
ABB控制器2CDG110215R0011產品介紹
用于風機盤管的控制。通過兩個模擬輸出，可以控制兩個模擬閥或一個六通閥驅動器以進行加熱和冷卻。對于風扇控制，該設備具有模擬輸出，用于控制連續風扇。繼電器輸出可切換高達 16 A 的附加負載，例如輔助加熱。超過 4 個輸入可以檢測和監控房間狀態（用于窗戶接觸、露點傳感器、液位傳感器或溫度傳感器）。還可以將一個模擬房間控制單元（SAR/A 或 SAF/A）連接到設備的輸入端。該設備具有集成的室溫控制器，用于控制室溫，可直接用于控制設備的輸出。FCC/S 1.3.2.1 具有易于使用的手動操作功能。
該設備支持 ABB i-bus 工具，以進行高級診斷和改進調試。
For the control of fan coil units. Via two analog outputs, two analog valves or one 6-way valve drive can be controlled for heating and cooling. For the fan control the devices features an analog output for the control of a continues fan. A relay output switches an additional load of up to 16 A, such as auxiliary heating. Over 4 inputs the room status can be detected and monitored (Use for window contact, dew point sensor, level sensor or temperature sensor). Also it is possible to connect one analog room control unit (SAR/A or SAF/A) to the inputs of the device. The device has an integrated room temperature controller for the control of the room temperature, which can be used directly to control the outputs of the device. The FCC/S 1.3.2.1 features an easy to use manual operation.
The device supports the ABB i-bus Tool for advanced diagnosis and improved commissioning.
ABB控制器其他常用型號：
ABB 2CDG120001R0011
ABB 2CDG110195R0011
ABB 2CDG110194R0011
ABB 2CDG110084R0011
ABB 2CDG110196R0011
ABB 2CDG110141R0011
ABB 2CDG110193R0011
ABB 2CDG110210R0011
ABB 2CDG110211R0011
ABB 2CDG110212R0011
ABB 2CDG110215R0011
ABB FAN COIL CONTROLLER NEW + ORIGINAL+ ONE YEAR WARRANTY
