REMBE防爆閥ODV系列技術參數
Standard burst pressure Pstat | 0.1 bar |
Max. permitted operating pressure | 80 % of Pstat |
Temperature | ? 148 to + 446 °F (? 100 to + 230 °C) |
Material | Stainless steel |
Tolerance | ± 15 % at standard burst pressure |
REMBE防爆閥ODV系列介紹
應用
REMBE ODV防爆閥用于真空至超壓循環操作條件。它設計用于高達靜態爆破壓力 80% 的工作壓力。ODV 非常適合用于需要頻繁噴射脈沖清潔的過濾器、高真空或抽吸輸送機等應用。它耐真空,標準爆炸壓力在 71.6 °F 時為 0.1 bar。
機制
當壓力升高時,ODV 防爆閥打開并將壓力從容器中釋放到周圍區域。
優勢
具有全真空阻力的低響應壓力是可能的。
防爆閥的高工作壓力阻力為工藝提供最大的生產率。
三層圓頂結構確保耐高壓循環和出色的使用壽命。
圓形版本和特殊定制解決方案是可能的。
Applications
The REMBE? ODV explosion vent is used under demanding vacuum to overpressure cyclic operating conditions. It is designed for working pressures of up to 80 % of static burst pressure. The ODV is ideal for use in applications such as filters with frequent jet-pulse cleaning, high vacuum or suction conveyors. It is vacuum resistant and the standard explosion pressure is 0.1 bar at 71.6 °F.
Mechanism
When pressure rises, the ODV explosion vent opens and releases pressure out of the vessel into the surrounding area.
Advantages
Low response pressure with full vacuum resistance is possible.
High working pressure resistance of the explosion vent offers maximum productivity for your processes.
Triple layered domed construction ensures high pressure cycling resistance and exceptional service life.
Rounded versions and special customized solutions are possible.
REMBE防爆閥ODV系列其他常用型號:
REMBE ODV-440x605
REMBE ODV-490x590
REMBE ODV-500x620
REMBE ODV-386x920
REMBE ODV-570x620
REMBE ODV-590x620
REMBE ODV-605x605
REMBE ODV-575x645
REMBE ODV-610x610
REMBE ODV-520x820
REMBE ODV-653x653
REMBE ODV-600x800
