ALFA UNION隔離開關STOL系列技術參數
ominal voltage | 750VDC / 1500VDC / 3000VDC |
Nominal current | 1000A / 2000A / 4000A / 6300A / 10000A / 12000A |
Number of poles | 36925 |
Version | manual |
Control voltage | 24 / 48 / 60 / 110 / 220VDC / 230VAC / 3x400VAC |
Ambient temperature | -25° - + 40°C |
Number of auxiliary contacts | 0 / 2 / 4 / 6 / 8 |
Overvoltage class | OV4 |
Pollution degree | PD4 |
Degree of protection | IP00 |
Mechanical lifetime | motorized version - 100 000 cycles |
According to standards | EN 50123 |
ALFA UNION隔離開關STOL系列介紹
STOL disconnectors are devices which are installed in stationary substations. They are used for no-load switching of electrical circuits. They are controlled either manually, with possibility of electromagnetic blocking of end positions, or by a motor unit with emergency control by a crank handle. The disconnector status is signalled by auxiliary contacts. Modular design of the STOL disconnector enables various versions.
STOL 隔離開關是安裝在固定變電站中的設備。它們用于電路的空載切換。它們既可以手動控制,也可以通過電磁鎖定終端位置,或者由帶有曲柄緊急控制的電機單元控制。 隔離開關狀態由輔助觸點發出信號。STOL隔離開關的模塊化設計支持各種版本。
ALFA UNION手動隔離開關STOL系列其他常用型號:
ALFA UNION STOL4021-MAB-R-220DC-1-8-A
ALFA UNION STOL4021-MO-R-220DC-1
ALFA UNION STOL4021-MAB-R-110DC-1-8-A
ALFA UNION SWITCH-DISCONNECTOR NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業集產品開發、設計、制造、銷售、于一體,代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣,液壓以及氣動解決方案的合作伙伴,我們利用我們的全球協作團隊,為客戶提供先進解決方案,市場知識以及相關增值服務來幫助優化客戶的工作效率,提高可靠性和安全性,致力于成為工業產品和解決方案的優質渠道。
如果有任何關于ALFA UNION手動隔離開關STOL4021-MAB-R-110DC-1-8-A的疑問,請隨時與我們溝通(021-31006702)。我們將盡全力解決您的問題。
If you have any question for ALFA UNION products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website: jjxdch.cn.
ALFA UNION手動隔離開關STOL系列STOL4021-MAB-R-110DC-1-8-A技術參數及介紹
