PIETRO FIORENTINI調壓閥FMF系列產品參數
Technical data | Value |
Accuracy class | 15 |
Closing pressure class SG | Pd+7.5 mbar o +30% according to EN88-1 |
Design pressure | 1 bar |
Design temperature | -15° C / +60° C |
Outlet pressure range of Wd | 5÷300 mbar |
Range of inlet pressure bpu | +2,5 mbar a +500 mbar - +1 or 201 wc in comparison to the outlet nominal pressure |
PIETRO FIORENTINI調壓閥FMF系列產品介紹
CSA設計認證的Z21.80 / CSA 6.22 I類管路壓力調節器，入口壓力為2 psig，出口壓力范圍為2英寸wc至?PSIG。GOVERNOR允許排氣孔限制*，多位置安裝和?到4“的正死端鎖定。GASGOVERNOR還具有雙隔膜，整體式排氣限制器和平衡閥設計，以提供更大的容量和精度。適用于室內和室外安裝GOVERNOR還獲得ANSI Z21.18認證（電器調節器）
CSA設計認證的Z21.80 / CSA 6.22帶有過壓保護（OPD）的I類管線壓力調節器，用于5 psig入口壓力，出口壓力范圍從2英寸wc到?PSIG。GASGOVERNOR允許通風口受限*，多位置安裝和?到2“的正死角鎖定。GAS GOVERNOR還具有雙隔膜，整體式排氣限制器和平衡閥設計，以提供更大的容量和精度。GASGOVERNOR適用于室內和室外安裝。
GAS GOVERNOR非認證型號可提供?“至4”管道尺寸，入口壓力為7 psig，出口壓力為2 psig?？商峁┮惑w式緊急關閉閥和過濾器。GASGOVERNOR適用于室內和室外安裝。
CSA design certified Z21.80/ CSA 6.22 Class I Line Pressure Regulator for 2 psig inlet pressure, outlet pressure range of 2 inches w.c. to ? PSIG. The GOVERNOR allows for vent limited*, multi-position installation, and positive dead-end lockup for ? through 4". The GAS GOVERNOR also features double diaphragm, integral vent limiter with balanced valve design to provide increased capacity and accuracy. The GOVERNOR is suitable for indoor and outdoor installation. The GOVERNOR is also certified ANSI Z21.18 (appliance regulators).
CSA design certified Z21.80/ CSA 6.22 Class I Line Pressure Regulator with Over Pressure Protection (OPD) for 5 psig inlet pressure, outlet pressure range of 2 inches w.c. to ? PSIG. The GAS GOVERNOR allows for vent limited*, multi-position installation and positive dead-end lockup for ? through 2". The GAS GOVERNOR also features double diaphragm, integral vent limiter with balanced valve design to provide increased capacity and accuracy. The GAS GOVERNOR is suitable for indoor and outdoor installation.
GAS GOVERNOR non-certified models are available from ?" through 4" pipe size, up to 7 psig inlet pressure and 2 psig outlet pressures. Integral slam-shut valves and filters are available. The GAS GOVERNOR is suitable for indoor and outdoor installation.
PIETRO FIORENTINI調壓閥FMF系列其他常見型號：
PIETRO FIORENTINI FMF30166F105AB
PIETRO FIORENTINI FMF3T15330DKSJ3
PIETRO FIORENTINI FMF301640007AB
PIETRO FIORENTINI FMF30061
PIETRO FIORENTINI Rotary Union NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于PIETRO FIORENTINI調壓閥FMF30061的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for PIETRO FIORENTINI products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website: .
PIETRO FIORENTINI調壓閥FMF系列FMF30061技術參數及介紹
