SIGMA易熔塞15RS57-255技術參數
Product Specifications | |
Flow Control Application | Normally Closed |
Control Functio | Two-Way - Stacked Ball |
Pressure Rating Body (Control Ports) | 10,000 PSI maximum (690 bar) |
Media Service | Hydraulic Fluid |
Temperature Service (Select) | 255℉ |
Connection Size (Body) | 1/4-18 Female N.P.T. Supply Inlet, Exhaust |
Orifice | 1/4 Diameter |
Cv Factor | 0.71 |
Wetted Component Material (Metal) | 316 Stainless Steel |
Seal Material | Viton |
Mounting | Field Mount (Standard) |
Weight | 1 Lb. |
Operating Temperature | -20° F to +250° F (-29° C to +121° C) |
Overall Dimensions | 3-3/8 Height x 1-1/2 Diameter (8.57 cm Height x 3.81 cm Diameter) |
SIGMA易熔塞介紹
15RS57熔斷閥是一種兩位置、雙向常閉的溫度敏感流量控制裝置。強烈的熱量或接近火源的高溫會融化保持閥門常閉流通路徑的固體共晶。當閥門受到超過驅動溫度的熱量時，會自動產生供氣到排氣的流通路徑。
熔斷閥用于關閉安全系統執行器，以隔離潛在燃料源與火災。
熔斷閥提供四種常用溫度：158°F、203°F、255°F和281°F。其他溫度可通過特殊訂單詢問獲得。
The 15RS57 Fusible Valve is a two position, two- way normally closed, Temperature Sensitive flow control device. Intense heat, or close proximity to a fire, will melt the solid Eutectic that maintains the valve's normally closed flow path. When the valve is subjected to heat that exceeds the actuation temperature, a Supply-to-Exhaust flow path will occur automatically.
Fusible Valves are used to shut-in or close safety system actuators to isolate potential fuel sources from fire.
Fusible Valves are available with four common temperatures:158°F, 203°F, 255°F and 281°F. Other temperatures are available through special order inquiry.
SIGMA易熔塞其他常用型號：
SIGMA 15RS57-255
SIGMA 15RS57-158
SIGMA 15RS57-203
SIGMA 15RS57-255
SIGMA Fusible plug NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于SIGMA易熔塞15RS57-255的疑問，請隨時與我們電聯，（021-3100 6702），我們將盡全力解決您的問題。
If you have any question for SIGMA products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website: jjxdch.cn.
