ANTAIRA網關STE-502C技術參數
SPECIFICATIONS | |
Power | 9 ~ 30VDC |
Led Displays | LAN, RUN, and COM |
Data Rate | 1200 ~ 230400 bps (230 Kbps) |
Storage Temperature | -20° C to 85° C (-4° F to 185° F) |
Power Consumption | 3 Watts |
Operating Temperature | 0° C to 60° C (32° F to 140° F) |
EEPROM | 512 Bytes |
Operating Humidity | 20% to 90% (Non-Condensing) |
CPU | 16-bit Embedded CPU |
Serial Connector | DB9 Male |
Dimensions | 85 x 75 x 28 mm (3.35 x 2.95 x 1.10 inches) |
Parity | None, Even, Odd, Mark, Space |
Stop Bits | 1 or 2 |
Flow Control | Xon/Xoff, RTC/CTS |
Protocols | TCP/IP, UDP, HTTP, SNMP, ARP, Telnet, ICMP, BOOTP, DHCP |
Flash Memory | 512 KBytes |
Approvals | FCC, CE |
SDRAM | 512 KBytes |
Software | Windows OS Based Configuration Utility, Virtual COM Software |
Warranty | 5-year Warranty |
Serial Interface | RS-232/422/485 |
Network Interface | 10/100Mbps Fast Ethernet |
Data Bits | 7 or 8 Data Bits |
Management | Web, Telnet, Serial Console, and Windows Based Utility |
ANTAIRA網關STE-502C產品介紹
STE-502C 是以太網 (TCP/IP) 和串行信號通信之間的雙端口網關。它允許幾乎任何串行設備連接到新的或現有的以太網網絡。通過封裝串行數據并通過以太網傳輸，STE-502C 可在串行端口和以太網網絡之間提供全雙工、雙向透明數據傳輸。STE-502C 能夠使用 RS232、RS422 或 RS485 串行通信標準，是將工業串行設備升級到以太網網絡的理想選擇。
特點
? 堅固的金屬外殼，帶 DIN 導軌/壁掛式安裝
? 串行信號 15 KV ESD 保護
? 10/100Mbps 快速以太網全雙工自動協商
? 支持多種鏈路模式，包括 TCP 服務器/客戶端、UDP 和虛擬 COM 模式
? 遠程監控、管理和控制工業現場設備
? 可通過內置 Web 服務器、串行控制臺或 Telnet 進行配置
? 基于 Windows 的 IP 配置實用程序
? 可通過以太網從遠程 PC 升級固件
The STE-502C is a dual port gateway between Ethernet (TCP/IP) and Serial signal communications. It allows almost any serial device to be connected to a new or existing Ethernet network. By encapsulating serial data and transporting it over Ethernet, the STE-502C offers full-duplex, bi-directional data transmission transparent between serial port and Ethernet network. Capable of using either RS232, RS422 or RS485 serial communication standards the STE-502C is ideal for upgrading industrial serial devices onto a Ethernet network.
Features
? Rugged Metal Case with DIN-Rail / Wall-Mount
? 15 KV ESD Protection for Serial Signals
? 10/100Mbps Fast Ethernet Full Duplex Auto Negotiation
? Supports Multiple Link Mode with TCP Server/Client, UDP, and Virtual COM Mode
? Monitor, Manage, and Control Industrial Field Devices Remotely
? Configurable via Built-in Web Server, Serial Console, or Telnet
? Windows Based Utility for IP Configuration
? Upgradeable Firmware from Remote-PC via Ethernet
