ISO壓力傳感器ISP系列技術參數
Technical specifications | |
Sensor | Thin film on steel |
Measuring range | 0 ÷ 60 to 0 ÷ 600 bar |
Output Signal | 4 ÷ 20 mA ; 0 ÷ 10 VDC |
Operating temperature | -25 + 85°C (standard) |
Media temperature | -25 + 85°C (standard) |
Protections | IP65; IP67 ( “M” option) |
Humidity | Max 95% relative |
Vibration | 25g (20 ÷ 2000Hz) |
Shock | 50 g/11ms Sin |
Material sensor | 1.4542 (AISI 630) |
Material Housing | 1.4301 (AISI 304) |
Material O-Ring (media contacting) | NBR or EPDM |
Mounting torque | 25 Nm |
Weight | ~ 50 g. |
Emission | EN/IEC 61000-6-3 |
Immunity | EN/IEC 61000-6-2 |
Output | 4 ÷ 20 mA / Supply voltage 24 (9 ÷ 32 ) VDC |
Rise time | typ. 1 ms/10 ÷ 90% nominal pressure |
Switch-on delay | 100 ms |
Load resistance | Output 4 ÷ 20 mA (USUPPLY - 9V)/20mA |
TEB @ -25 + 85°C | ± 1.75 [%fs Typ] |
Accuracy @ + 25°C | ± 0.5 [%fs Typ] |
NLH @ + 25°C (BSL through 0) | ± 0.2 [%fs Typ] |
TC zero point and span | ± 0.03 [%fs/K Typ] |
Long term stability 1 year @ + 25°C | ± 0.2 [%fs Typ] |
ISO壓力傳感器ISP系列介紹
ISP 型壓力傳感器提供與輸入液壓成比例的輸出信號
由不銹鋼實心件制成的機身設計和加工使這些組件適用于移動和工業用途。
壓力傳感器ISP符合最新的CE標準，并提供多種配置選擇：根據電氣連接、輸出和液壓連接。
The pressure transducers type ISP give an output signal ( tension or current ) proportional to the incoming hydraulic pressure.
The design and machining of the body from a stainless steel solid piece make these components suitable for mobile and industrial use.
The pressure transducers ISP meet latest CE standards and offer a wide selection of configuration: according to the electric connection, output and hydraulic connection.
ISO壓力傳感器ISP系列其他常用型號：
ISO ISP-060/V-D-CE
ISO ISP-100/V-D-CE
ISO ISP-250/V-D-CE
ISO ISP-350/V-D-CE
ISO ISP-400/V-D-CE
ISO ISP-600/V-D-CE
ISO ISP-400/I/D-CE
