J+J電動執行器J3-L20技術參數
Voltage range - automatically sensed by actuator | 12-24 AC (1ph) or DC |
Operating time (0-90° no load) | 9 seconds |
Maximum break torque | 25 Nm |
Maximum operating torque (run/ reseat) | 20 Nm |
Duty rating | 75% |
IP Rating (IEC 60529) | IP65 |
Working angle Standard (on request) | 90° (180° or 270° options) |
Mounting ISO:5211 x DIN 3337 | F03, F04 & F05 x 14 |
Motor switches | 2 x SPDT micro switches |
End of travel confirmation (volt free) | 2 x SPDT micro switches |
Heater | 4 W |
Ambient temperature range | -20° to +60° C |
Electrical connecting plugs | DIN 43650/ ISO4400 & C192 |
Weight | 1.5 kg |
Housing | Anti-corrosive Polyamide |
Fasteners | Stainless steel |
Gears | Polyamide (speed reducing) & steel |
Shaft | Stainless steel |
Output drive | Zammac |
Position indicator | Glass filled Polyamide |
J+J電動執行器J3系列介紹
J3 采用全新、堅固耐用的防風雨和防腐蝕聚酰胺外殼，提供比 J2 更人性化的功能，并引入了高度可見的 LED 狀態燈。
該視覺指示器顯示執行器是否正常運行，或者是否被其電子扭矩限制器跳閘，或者是否處于“手動”模式。
With an all new, rugged weatherproof and anti-corrosive Polyamide housing, the J3 offers more user-friendly features than the J2, and introduces a highly visible LED status light.
This visual indicator shows whether the actuator is operating correctly, or has tripped out either by its electronic torque limiter, or has been left in ‘manual’ mode.
J+J電動執行器J3系列其他常用型號：
J+J J3-L20
J+J J3-L35
J+J J3-L55
J+J J3-L85
J+J J3-L140
J+J J3-L300
J+J J4-S20
J+J J3C-L20
J+J J4C-S20
J+J Actuator NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于J+J電動執行器J3-L20的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question forJ+J products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:jjxdch.cn.
