CONTROL TECHNIQUES驅動器MP系列介紹
Mentor MP
Modern, cost effective DC drive with excellent system integration flexibility
25 A – 7,400 A (5 HP – 6,080 HP)
24 V - 480 V | 575 V | 690 V
Control Techniques’ Mentor MP brings DC drive technology up to date, enabling existing and new DC motors to provide economic and productive service.
DC drive technology remains cost effective, efficient and is relatively simple to implement.
Specifications
Models available for two or four quadrant (regenerative) operation
25 A to 7400 A, 24 V - 480 V | 500 V - 575 V | 500 V - 690 V
Optional high-brightness LED or multi-language LCD keypad, simple configuration using plain text
Modular parallel connection for higher power motor operation
12/24 pulse operation to minimize harmonics
IP20 (NEMA 1) protection for size 1, IP10 (open chassis) for size 2A and 2B, and IP00 (open chassis) for size 2C and 2D for easy, low cost installation
Integrated drive and motor protection for:
Over current
Over temperature
Phase loss
SCR/Thyristor junction temperature
Feedback loss
Field loss
Armature open circuit
Internal field controller with intelligent field weakening means that for 90% of applications no additional external controller is required
Frame size 1 to 8 A
Frame size 2 to 20 A
Flux control for enhanced open loop performance
Optional FXMP25 external field controller for current fields up to 25 A
Digital link for field control from Mentor MP or Mentor II
Standalone digital control mode for simple application
Flux control for enhanced open loop performance
Intelligent field weakening
Field forcing – for high dynamic machine reversal
Field reversal – low dynamic machine reversing using two quadrant main stack
Mentor MP size 1 can be used for fields greater than 25 A
Serial port for Modbus RTU and PC communications
3 Universal option module slots, allowing Mentor MP to benefit from the solutions developed for Control Techniques market leading AC drive technology.
Each option slot allows:
High performance PLC and motion control
Ethernet and Fieldbus communications
Connectivity to additional feedback devices
Additional I/O
Galvanically isolated control
Smartcard for drive parameter back-up and copying, allowing rapid installation and maintenance
Integrated PLC as standard
Standard software features for easy integration
PID controller
Motorized potentiometer
Digital lock (Slave operation from master encoder)
Open loop control using estimated speed advanced processing based on armature voltage and field flux feedback
Closed loop control using
Tacho-generator feedback for connection to traditional DC motor
Incremental encoder feedback for higher accuracy and position control
Optional SinCos, SSI, Hiperface and EnDAT connectivity for high performance applications
High performance control strategy
32 bit microprocessor
35μs current sampling time
Speed controller and ramps update 250 μs
Autotune features for armature, field current loops and speed loop
Current ratings
The power ratings for the 230 V, 480 V, 575 V and 690 V configurations are shown below.
The continuous current ratings given are for a maximum ambient temperature of 40 °C (104 °F) and an altitude of 1000 m (3,300 ft). For operation at higher temperatures and altitudes de-rating is required. Overload of 150 % for 30 s is available with ambient temperature of 40 °C (104 °F) up to a maximum of 10 repetitions per hour.
MP系列
現代、經濟高效的直流驅動器，具有出色的系統集成靈活性
25 A – 7,400 A (5 HP – 6,080 HP)
24 伏 - 480 伏 | 575 伏 | 690 伏
Control Techniques 的 Mentor MP 帶來了最新的直流驅動技術，使現有和新的直流電機能夠提供經濟和高效的服務。
直流驅動技術仍然具有成本效益、高效且實施起來相對簡單。
規格
可用于二象限或四象限（再生）運行的型號
25 A 至 7400 A，24 V - 480 V | 500 伏 - 575 伏 | 500 伏 - 690 伏
可選高亮度 LED 或多語言 LCD 鍵盤，使用純文本進行簡單配置
用于更高功率電機運行的模塊化并聯連接
12/24 脈沖操作以最大限度地減少諧波
尺寸 1 防護等級為 IP20 (NEMA 1)，尺寸 2A 和 2B 防護等級為 IP10（開放式機箱），尺寸 2C 和 2D 防護等級為 IP00（開放式機箱），安裝簡單、成本低
集成驅動和電機保護：
過電流
過溫
缺相
可控硅/晶閘管結溫
反饋損失
場損失
電樞開路
具有智能弱磁功能的內部勵磁控制器意味著 90% 的應用不需要額外的外部控制器
框架尺寸 1 至 8 A
框架尺寸 2 至 20 A
用于增強開環性能的通量控制
可選的 FXMP25 外部磁場控制器，用于高達 25 A 的電流場
Mentor MP 或 Mentor II 現場控制的數字鏈接
獨立數字控制模式，應用簡單
用于增強開環性能的通量控制
智能弱磁
磁場強制 – 用于高動態機器反轉
場反轉 - 使用兩個象限主堆棧的低動態機器反轉
Mentor MP size 1 可用于大于 25 A 的場
用于 Modbus RTU 和 PC 通信的串行端口
3 個通用選項模塊插槽，使 Mentor MP 能夠受益于為 Control Techniques 市場領先的交流驅動技術開發的解決方案。
每個選項插槽允許：
高性能 PLC 和運動控制
以太網和現場總線通信
與其他反饋設備的連接
額外的 I/O
電隔離控制
用于驅動器參數備份和復制的智能卡，允許快速安裝和維護
標準集成PLC
易于集成的標準軟件功能
PID控制器
電動電位器
數字鎖（主編碼器的從操作）
使用基于電樞電壓和勵磁磁通反饋的估計速度高級處理的開環控制
閉環控制使用
用于連接傳統直流電機的測速發電機反饋
增量編碼器反饋可實現更高的精度和位置控制
用于高性能應用的可選 SinCos、SSI、Hiperface 和 EnDAT 連接
高性能控制策略
32位微處理器
35μs電流采樣時間
速度控制器和斜坡更新 250 μs
電樞、勵磁電流回路和速度回路的自動調諧功能
當前評級
230 V、480 V、575 V 和 690 V 配置的額定功率如下所示。
給出的連續電流額定值適用于 40 °C (104 °F) 的最高環境溫度和 1000 m (3,300 ft) 的海拔高度。對于在更高溫度和海拔高度下運行，需要降低額定值。環境溫度為 40 °C (104 °F) 時，可提供 150 % 的 30 秒過載，每小時最多重復 10 次。
