ABB網關SPA-ZC 302-BA規格描述
Technical data | |
Interfaces | |
Profibus DP version 1 interface | ? RS-485 twisted pair |
SPA bus interface | ? RS-232, RS-485 or TTL levels |
Power supply | |
SPA-ZC 302 | ? Input voltage: 110 V...240 V AC/DC |
Environmental conditions | |
Specified ambient service temperature range | -10...+55oC |
Transport and storage temperature range | -40...+70oC |
Maximum relative humidity (without condenzation) | 95% |
Environmental tests | |
Dry heat test according to IEC 60068-2-2 | +55oC |
Dry cold test according to IEC 60068-2-1 | -10oC |
Damp heat test according to IEC 60068-2-30 | RH > 93%, 55oC, 6 cycles |
Degree of protection by enclosure of the device case according to IEC 60529 | IP20 |
ABB網關SPA-ZC 302-BA產品介紹
Profibus-DP / SPA-gateway SPA-ZC 302
Profibus DP Version 1 connectivity for devices with SPA bus interface
The SPA-ZC 302 is an interface module for SPA bus protection relays, that provides con-nectivity to the Profibus DP fieldbus. The Profibus DP specification and the structure of its messages are defined in the European stan-dard EN50170.
Scope
The SPA-ZC 302 is an interface module for SPA bus protection relays, that provides connectivity to the Profibus DP fieldbus
Product benefits
Easy-to-use configuration tool
Library of pre-defined standard configurations
Product features
Auxiliary power supply
Support of battery voltage levels used in power systems
High immunity to electrical and electromagnetical interference
Profibus-DP / SPA網關SPA-ZC 302
具有SPA總線接口的設備的Profibus DP版本1連接
SPA-ZC 302是用于SPA總線保護繼電器的接口模塊，可提供與Profibus DP現場總線的連接。 Profibus DP規范及其消息的結構在歐洲標準EN50170中定義。
范圍
SPA-ZC 302是用于SPA總線保護繼電器的接口模塊，可提供與Profibus DP現場總線的連接
產品優勢
易于使用的配置工具
預定義標準配置庫
產品特點
輔助電源
支持電力系統中使用的電池電壓水平
高度抗電磁干擾
ABB網關其他常見型號:
ABB SPA-ZC 302-BA
ABB SPA-ZC 302-AA
