Enclosure

? Standard: weatherproof enclosure IP67, NEMA 4, 4X, 6
? Watertight enclosure: IP68 (10 m, 72 hours)
? Flameproof enclosure: Ex db IIB T4
? Dust ignition proof enclosure: Ex tb IIIC T135°C

Certificates & approvals

? IECEx (Ex db IIB T4 Gb, Ex tb IIIC T135°C Db)
? ATEX (II 2G Ex db IIB T4 Gb, II 2D Ex tb IIIC T135°C Db)
? KCs (Ex d IIB T4, Ex tD A21 IP6X, T135°C)
? EAC (1 Ex db IIB T4 Gb X, Ex tb IIIC T135°C Db)
? CSA (Class I, Division 1, Groups C,D T4; Ex d IIB T4 Gb)
? CCC (Ex d IIB T4 Gb, Ex tD A21 IP6X T135°C)
? SIL 2
? RMRS type approval
? ABS type approval
? Türk Loydu type approval
? RINA type approval
? USCG test approval

Torque

? 80~9,000 Nm

Power

? 110/220 V ac 1ph, 50/60 Hz, ±10%
? 220/380/440/480 V ac 3ph, 50/60 Hz, ±10%
? 12 V dc (HQ-008, 010)
? 24 V dc (HQ-008 to HQ-300)
? 24 V ac/dc (HQ-008 to HQ-300)

Duty cycle

? S2(on-off): 30 mins
? S4(modulating): 70% 800-1200 starts/hour (room temp., average load of 50% of max. torque)

Travel angle

? Standard: 0~90°
? Extension: 0~120°, 135°, 180°, 270°, etc.

Ambient temperature

? Standard: -20 to +70 °C
? Flameproof/dust ignition proof: -20 to +60 °C
? Low temperature: -60 to +60 °C (EAC)

Cable entries

? Standard: 2 x PF3/4″ (HQ-008 to HQ-300), 2 x PF3/4″ + PF 1″ (HQ-350 to HQ-900)
? Flameproof/dust ignition proof: 2 x NPT3/4″ or 2 X M25

Limit switches

? Standard: 2 x SPDT (16 A 250 V ac) (HQ-008, 010), 4 x SPDT (16 A 250 V ac) (HQ-015 to 900)
? Additional Limit Switches(ALS): +2 x SPDT

Torque switches

? Standard: 2 x SPDT (16 A 250 V ac) (except HQ-008,010)
? Additional Torque Switches(ATS): +2 x SPDT (except HQ-008, 010)

Space heater

? HQ-008, 010: 5 W
? HQ-015 to HQ-900: 10 W

Control option

? PIU: Potentiometer unit (0-1 kΩ)
? CPT: Current Position Transmitter (output: 4-20 mA dc)
? PCU: Proportional Control Unit (intput/output: 0-10 V dc or 4-20 mA dc)
? PROFIBUS DP interface modules
? MODBUS modules
? CANopen modules
