TELCO光電放大器PA12B/A系列技術參數
Product Data | |
Electrical Data | |
Supply voltage | 24Vdc,24Vac,115Vacor230Vac |
Voltage tolerance | +/- 15% |
Power consumption | Max.3 VA |
Output: relay | 1 open/ 1 closed, 250 V ac/3A, 120 V ac/5 A |
Output: NPN transistor | 40mA/30Vdc |
Output: PNP transistor | 5mA/12Vdc(forPA12AVB003:40mA/24Vdc) |
Environmental Data | |
Temperature, operation | -10 to +50 oC |
Sealing class | IP 40 |
TELCO光電放大器PA12B/A系列介紹
PA 12 光電放大器允許使用最多四個具有不同頻率的獨立放大器和傳感器，從而顯著降低串?dāng)_風險。但是，需要指出的是，如果兩個或多個傳感器組在密閉空間內運行，并且相鄰信號過高，則可能會發生串?dāng)_。
可以使用撥碼開關 no 3 和 no 4 選擇四種不同的發射器頻率。
The PA 12 photo amplifier allows to use, up to four individual amplifiers and sensors with different frequencies that reduce the risk of cross-talk significantly. However, it is important to point out, that if two or more sensors sets are in operation within a confined space, and if the neighbour signal gets too high, cross-talk may occur.
Four different transmitter frequencies can be selected with dip switch no 3 and no 4.
TELCO光電放大器PA12系列其他常用型號：
TELCO PA12B003+TR11B
TELCO PHOTOELECTRIC AMPLIFIER NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于TELCO光電放大器PA12B003+TR11B的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for TELCO products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:jjxdch.cn.
TELCO光電放大器PA12B/A系列PA12B003+TR11B技術參數
