WIDAP電位器MA800型產品參數
Specification | |
Potentiometer | Type DP 3 according to sheet 10-4-10, type DP 60 according to sheet 10-4-30 Executions with type DP 170 or type DP 300 on request |
Switch | Single pole snap switch |
Switch actuation | By two-piece cam disc, any switch angle can be adjusted Normaly two switches as motor limit switch |
Switch power | 6 (2) A, 250 V AC (according to ENEC) |
Drive | Permanent magneto motor up to 48 V DC and (24V AC up to 230 V AC, 50/60 Hz with logic module) |
Cycle time | On requiry |
Manual adjustement | Is possible due to incorporate friction clutch |
Special executions | On request |
Drawing | Sheet 10-7-11 |
WIDAP電位器MA800型產品介紹
建設與執行
MA800型電位器可配備DC或AC電動機，714型電位器和718型DC電動機。具有限制和控制開關的多次執行是可能的。
特征
操作可靠性高
長壽命裝置
要求的循環時間
應用領域
在電工技術和電子學中有各種應用領域。
Construction and execution
Our potentiometers type MA800 can be equipped with DC or AC motors, the potentiometers type 714 and type 718 with DC motors. Multiple executions with limitation and control switches are possible.
Features
High operation reliability
Longlife device
Cycle time on requiry
Application fields
There are various application fields in electro-technics and electronics.
WIDAP電位器7700-1014
WIDAP電位器7700-1014其他常見型號：
WIDAP 7700-1014
WIDAP MA800
WIDAP 714
WIDAP 718
WIDAP potentiometers NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于WIDAP電位器7700-1014的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for WIDAP products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website: jjxdch.cn.
WIDAP電位器7700-1014產品參數
