BALDOR電機R25-A000-0387產品參數
Enclosure | DPFV |
Frame | RDL1611Y |
Frame Material | Exposed Laminations |
Frequency | 513.00 Hz |
Phase | 3 |
Synchronous Speed @ Frequency | 3600 RPM @ 513 HZ |
Voltage @ Frequency | 380.0 V @ 513 HZ |
Agency Approvals | CCSA US |
Auxillary Box | No Auxillary Box |
Base Indicator | Rigid |
Bearing Grease Type | Kluberquiet BQ 72-72 |
Current @ Voltage | 176.000 A @ 380.0 V |
Duty Rating | S1 |
Feedback Device | ENCODER |
High Voltage Full Load Amps | 176.0 a |
Frame Prefix | RDL |
Heater Indicator | No Heater |
Insulation Class | H |
IP Rating | NONE |
Mounting Arrangement | F2 |
Overall Length | 39.29 IN |
Product Family | General Industrial |
Pulley End Bearing Type | Ball |
Service Factor | 1 |
Shaft Diameter | 2.166 IN |
Shaft Ground Indicator | No Shaft Grounding |
Shaft Rotation | Reversible |
Speed | 4500 rpm |
Motor Standards | IEC |
Starting Method | Full Voltage |
Thermal Device - Bearing | None |
Thermal Device - Winding | Normally Closed Thermostat |
BALDOR電機其他常見型號：
BALDOR R25-A000-0387
BALDOR R25-A000-0365
BALDOR R25-A000-0362
BALDOR R25-A000-0364
BALDOR R25-A000-0025
