BUSAK+SHAMBAN(B+S) V型封V-425L產品參數
For Shaft Diameter d1 | 410 - 440 |
Inside Diameter d | 382 |
V-Ring FORSHEDA Ref. | V-425L/LX |
TSS Part No. Type L | TWVL04250 |
TSS Part No. Type LX | TWLXV4250 |
BUSAK+SHAMBAN(B+S) V型封產品介紹
Trim the adjustable clamping band to the right length by using a pair of shears. Rivet the adjustable length and the end attachment together by using a standard pop riveter and the three pop rivets.
Locate the V-Ring in correct position relative to the counterface, i.e. the predetermined B1 dimension.
Smear the V-Ring with a thin film of grease in the groove designed for the clamping band.
Using the attachments supplied with the band sections, join them together and position the complete band in the body groove with the screw heads facing the direction of shaft rotation. Turn the attachment screws a few turns one by one until the band is tight.
Check that the entire band fits snugly in the body groove.
The clamping band A/AX is meant to be used with V-Rings type A and AX on shaft diameters from 200mm and larger. The clamping band keeps the V-ring in position both axially and radially and can be re-used several times. The clamping band is supplied in 5m lengths. Screw joints to connect the clamping band as well as the buckle are ordered on separate article number. The band is made of stainless steel AISI 301, the screw joint is made of AISI 304 with galvanized screw.
使用一把剪刀將可調節夾帶修剪到合適的長度。使用標準流行鉚釘和三個流行鉚釘將可調節長度和末端附件鉚接在一起。
將 V 形環定位在相對于配合面的正確位置，即預定的 B1 尺寸。
在為夾緊帶設計的凹槽中，在 V 形環上涂抹一層薄薄的油脂。
使用帶子部分隨附的附件將它們連接在一起，并將整個帶子放置在主體凹槽中，螺釘頭朝向軸的旋轉方向。將連接螺釘一一轉動幾圈，直到帶子擰緊。
檢查整個帶子是否緊貼在主體凹槽中。
夾緊帶 A/AX 旨在與 A 型和AX型V型圈一起用于200毫米及更大的軸直徑。夾緊帶將 V 形環保持在軸向和徑向位置，并可多次重復使用。夾緊帶的長度為5m。用于連接卡箍和帶扣的螺紋接頭在單獨的訂貨號中訂購。表帶由不銹鋼AISI 301制成，螺紋接頭由 AISI 304 制成，帶有鍍鋅螺釘。
BUSAK+SHAMBAN(B+S) V型封其他常見型號：
BUSAK+SHAMBAN(B+S) V-425L
BUSAK+SHAMBAN(B+S) TWVL 04000
BUSAK+SHAMBAN(B+S) TWVL04250
BUSAK+SHAMBAN(B+S) TWVL 04500
BUSAK+SHAMBAN(B+S) TWVLV5000
BUSAK+SHAMBAN(B+S) TWVLV5250
BUSAK+SHAMBAN(B+S) TWVLV5500
BUSAK+SHAMBAN(B+S) TWVLV6000
BUSAK+SHAMBAN(B+S) TWVLV6500
BUSAK+SHAMBAN(B+S) TWVLV7000
BUSAK+SHAMBAN(B+S) Seal NEW + ORIGINAL+ ONE YEAR WARRANTY
