MP FILTRI濾芯HP320系列產品參數
Specification | |
Filter housing materials | Head: Phosphatized cast iron |
Bypass valve | AISI 316L (FHP 010 - 01 1) |
Reverse Flow | Steel (FHP 320-FHP 500) |
Check valve | Steel |
Pressure | |
Working pressure | 42 MPa (420 bar) |
Test pressure | 63 MPa (630 bar) |
Burst pressure: | 126 MPa (1260 bar) |
Pulse pressure fatigue test | 1 000 000 cycles with pressure from O to 42 MPa (420 bar) |
Bypass valve | Opening pressure 600 kPa (6 bar) |
AP element type | |
Microfibre filter elements series N | 20 bar |
Microfibre filter elements series R: | 20 bar(not available for FHP 010-011 and FHP 500) |
Microfibre filter elements series H: | 210 bar |
Microfibre filter elements series S: | 210 bar(only for FHP 500) |
Wire mesh filter elements - series N: | 20 bar |
Fluid flow through the filter element from OUT to IN. | |
Seals | |
Standard NBR series A | |
Optional FPM series V | |
Temperature | From -25 oc to +110 oc |
Connections | |
FHP 010 065 135 500: | In-line Inlet/0utIet |
FHP 011 - 320: | 900 Inlet/Outlet |
MP FILTRI濾芯HP320系列產品介紹
正確的過濾器尺寸必須取決于應用的可變壓降。例如，對于回油過濾器，壓降必須在0.4-0.6 bar的范圍內。
通過將外殼的值與過濾器元件的值相加來執行壓降計算。外殼中的壓降與流體密度（kg/dm3）成正比；目錄中的所有圖形均指密度為0.86 kg/dm3的礦物油。
濾芯壓降與其粘度（mm2/s）成正比，校正系數Y與不同于30 mm2/s的機油粘度有關。
The correct filter sizing have to be based on the variable pressure drop depending by the application. For example, for the return filter the pressure drop have to be in the range 0.4 - 0.6 bar.
The pressure drop calculation is performed by adding together the value of the housing with the value of the filter element. The pressure drop in the housing is proportional to the fluid density (kg/dm3); all the graphs in the catalogue are referred to mineral oil with density of 0.86 kg/dm3.
The filter element pressure drop is proportional to its viscosity (mm2/s),the corrective factor Y is related to an oil viscosity different than 30 mm2/s.
選型參考
MP FILTRI濾芯HP320系列其他常見型號：
MP FILTRI HP3201A03ANP01
MP FILTRI HP3202A03ANP01
MP FILTRI HP3203A03ANP01
MP FILTRI HP3204A03ANP01
MP FILTRI HP3201A03VNP01
MP FILTRI HP3202A03VNP01
MP FILTRI HP3203A03VNP01
MP FILTRI HP3204A03VNP01
MP FILTRI HP3201A03AHP01
MP FILTRI HP3202A03AHP01
MP FILTRI filter NEW + ORIGINAL+ ONE YEAR WARRANTY
