Marking:

Standard

Signal Output:

+10...0...-10 V

Port Connection:

NG06 / CETOP 03

Operation Type:

Direct

Spool Type:

Overlap

Electronics Type:

Onboard

Pressure Differential:

5 bar

Spool Code:

E01, equal metering, 4-way, 3 position, all ports open

Spool Design:

Spool/body

Flow Rate:

20 L/MIN

Defined Spool Position At Power Down:

Center position

Mounting Type:

Subplate

Seal Material:

FPM

Actuation Type:

Proportional, Solenoid

Signal Input:

0 to ±10 V

Weight:

3.4 kg

Product Series:

Proportional DC Valve

Function:

0 to 10 V = P-A

Maximum Flow Rate:

n/a

Connection Type:

6 + PE

Maximum Operating Pressure:

350 bar

Maximum Ambient Temperature:

60 °C

Minimum Ambient Temperature:

-20 °C

For Fluid Type:

Water-Glycol

Function:

3-way

Seal Material:

FPM

Body Material:

Cast Iron

Maximum Fluid Temperature:

60 °C

Minimum Fluid Temperature:

-20 °C

Maximum Kinematic Viscosity:

400 cSt

Minimum Kinematic Viscosity:

20 cSt

Vibration Resistance:

10 Sinus 5...2000 Hz Acc. IEC 68-2-6, 10 (RMS) Random Noise 20...2000 Hz Acc. IEC 68-2-36, 15 Shock Acc. IEC 68-2-27

Mounting Position:

Unrestricted

Filter Efficiency Rating:

ISO 4406; 18/16/13

Leak Rate:

<50 (overlap spool)

Variation of Opening Point:

set to 10 % command signal

Response Time:

20 ms

Hysteresis:

< 0,1 %

Ingress Protection Rating:

IP65 in accordance with EN 60529

Power Supply Voltage:

18...30, electric shut-off at < 17, ripple < 5 % eff., surge free V

Mounting Style:

DIN 24340 / ISO 4401 / CETOP RP121 / NFPA
