END ARMATUREN執行器ZA310068-ED630852規格介紹
Technische Details | |
SKU | ZA310068 |
Description | Ball valve DN65, PN64, 1.4408 / PTFE FKM, Weld ends, ISO 5211, DIN3202-S13 |
Weight [kg] | 9.858000 |
Approvales | TA Luft |
Size | DN65 |
Body material | Stainless Steel |
Seals material | PTFE |
Stem seals material | PTFE/FKM/Graphit |
Operation | for actuator-mounting |
Execution | DIN/EN-length |
Connection type | Welding Connection DIN3239 |
Connection size | DN65 |
Nominal pressure min. [bar] | 0 |
Nominal pressure max. [bar] | 64 |
Body test pressure PT [bar] | 96 |
Temperature range min. [°C] | 0 |
Temperature range max. [°C] | +80 |
Media temperature min. [°C] | -30 |
Media temperature max. [°C] | +180 |
Geh盲usedesign | 3-teilig |
Technische Details | |
SKU | ED630852 |
Description | Pivoting drive DW85, DIN, F05 / 07, 8kt.17, FKM seal, double acting, to + 140 o C |
Weight [kg] | 4.270000 |
Size | ?85 |
Body material | Aluminium |
Function | double acting |
Torque | 63Nm at 6bar pilot pressure |
Seals material | FKM - max. 140°C ambient temperature |
Temperature range min. [°C] | -20 |
Temperature range max. [°C] | +140 |
Media temperature min. [°C] | -20 |
Media temperature max. [°C] | +140 |
常用備件END ARMATUREN執行器部分型號：
END ARMATUREN ZA310068-ED630852
END ARMATUREN ZA310068/HT-ED630852
END ARMATUREN ZA310069/HT-ED630852
END ARMATUREN ZA310029/HT-ED630852
END ARMATUREN ZA310065/HT-EE630852
END ARMATUREN ZA310064/HT-EE630852
END ARMATUREN ZA310026/HT-EE630852
END ARMATUREN ZA310063/HT-ED630552
END ARMATUREN ZA310064/HT-ED630552
END ARMATUREN ZA310025/HT-EE630852
END ARMATUREN ZA310368-ED620852/AX
END ARMATUREN ZA310025/HT-ED630552
END ARMATUREN ZA310024/HT-ED630552
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于END ARMATUREN執行器ZA310068-ED630852的疑問，請隨時與我們聯系（021-31006702）。我們將盡全力解決您的問題。
有關END ARMATUREN執行器ZA310068-ED630852更詳細的信息或者購買END ARMATUREN相關產品，請聯系愛澤工業。
If you have any question, please feel free to dial 0086-21-3100 6702 or browse our website: jjxdch.cn.
END ARMATUREN執行器ZA310068-ED630852介紹
