AIR-MASTERS離子風刀10002X技術參數
Blowing force at 72.5 PSI | 5.04 OZ |
Air consumption at 72.5 PSI | 5.29 SCFM |
Air Amplification | 40:1 |
Sound level at 72.5 PSI | 67dB(A) |
Material | Anodised aluminum, hard anodised aluminum and stainless steel |
Shims | Stainless steel |
Dimensions | 2.01" x 1.75" x 1.09" (51 mm x 44.5 mm x 27.6 mm) |
Connection type | Female |
Back connection | 1/4" x 1 |
Blowing pattern | Flat |
Velocity at 152mm | 57 m/s |
Max operating pressure | 145 PSI |
AIR-MASTERS離子風刀10002X產品介紹
AIRMASTERS Air Blade離子風刀已被證明具有高質量、高性能和安靜的設計產品，適用于所有類型的吹氣和冷卻應用。省去一排鉆孔管可以節省高達 90% 的壓縮空氣成本。
離子風刀由鋁制成并經過涂層處理，使用壽命長。不銹鋼型號可用于高溫和腐蝕性應用。生產的另一個版本是“硬化陽極氧化鋁”AIRMASTERS 空離子風刀片，有時可以消除使用更昂貴和更重的不銹鋼裝置的需要，并節省數倍的成本。離子風刀配有不銹鋼墊片以設置氣隙（大多數其他離子風刀使用廉價塑料，會很快磨損）并用不銹鋼螺釘固定在一起。它們也可以使用連接套件連接在一起以獲得更長的跨度。
The AIRMASTERS Air Blade Air Knife has proven to be of high quality, high performance and one of the most quiet, if not "the most quiet" designs on the market for all types of blow-off and cooling applications. Eliminating a row of drilled pipe can save up to 90% of compressed air costs.
Air knives are made of aluminum and coated for long life. Stainless steel models are available for high temperature and corrosive applications. Another version that we produce is the “Hardened anodized aluminum” AIRMASTERS air blade, that can sometimes eliminate the need to go to more costly and heavy stainless steel units and save hundreds of pounds in cost! Air knives comes complete with a stainless steel shim to set the air gap (most others use cheap plastic which can wear out quickly) and are held together with stainless steel screws. They can also be coupled together using a coupling kit for longer spans.
AIR-MASTERS離子風刀其他常用型號：
AIR-MASTERS 10002X
AIR-MASTERS 10003X
AIR-MASTERS 10006X
AIR-MASTERS 10009X
AIR-MASTERS 100012X
AIR-MASTERS 100015X
AIR-MASTERS 100018X
AIR-MASTERS 100024X
AIR-MASTERS Air Knife NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于AIR-MASTERS離子風刀10002X的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for AIR-MASTERS products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:jjxdch.cn.
