SOMMER噴霧器ZMIN系列規格描述
Technical data | |
Operating pressure | 5 - 8 bar |
Environmental temp. | -25 °C... +80 °C |
Viscosity range | 1 - 150 mm2/sec. at 20 °C |
Max. cycle frequency | 60/min. |
Spray angle | 30° |
Max. air consumpt. | 58 l norm./min. |
SSound level | 75 dB/with metal hose: 76 dB |
Material | Anodized aluminum, nickel-plated brass,seals PTFE + 25 % carbon, NBR |
SOMMER噴霧器ZMIN系列產品簡介
不吸油，而是從頂部注入油。因此，幾乎不需要空氣。霧化器內部安裝了一個油截止閥。霧化器一接收到壓縮空氣，就會打開油閥，并同時涂抹已分配的油。
最小霧化器ZMIN具有內置的流體截止閥。它僅在實際可用壓縮空氣時切換為流動，并在壓縮空氣中斷時立即阻止流體進料。這簡化了控制，因?yàn)榉磻?yīng)僅根據壓縮空氣發生，例如通過我們的3/2方向閥進行。
可以簡單地從上方（例如，通過與容器的連接）輸入流體。因此ZMIN可以在很少的空氣下運行。
噴霧模式可以在霧化器和流體感應器上調節。
空氣越霧化，液滴越細。
The oil is not suctioned, but fed in from the top. Thus, very little air is needed. An oil shut-off valve is installed inside the atomizer. As soon as the atomizer receives compressed air, the oil valve opens up and the dosed oil is applied simultaneously.
The minimal-atomizer ZMIN has a built-in fluid shut-off valve. It only switches to flow when compressed air is actually available and blocks the fluid infeed immediately when the compressed air is interrupted. This simplifies control, because a reaction only takes place in dependence of the compressed air, e.g. via our 3/2 way valve.
The fluid is simply fed in from above (e.g. through the connection with the container). So the ZMIN can operate with very little air.
The spray pattern can be adjusted on the atomizer and the fluid inductor.
The more atomized air, the finer the droplets.
SOMMER噴霧器其他常用型號：
SOMMER ZMIN
SOMMER ZMIN-V60
SOMMER ZMIN-MS
SOMMER EZMIN-MS
SOMMER ATOMIZER NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于SOMMER噴霧器ZMIN-MS的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for SOMMER products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:jjxdch.cn.
SOMMER噴霧器ZMIN系列ZMIN-MS產品參數
