ARDUCAM攝像頭模塊B0304技術參數
Specifications | |
Sensor | IMX708 |
Resolution | 12MP |
Color Filter Type | Color |
Shutter Type | Rolling Shutter |
Optical Size | 1/2.43” |
Output Format | MJPG |
Pixel Size | 1.4μm × 1.4μm |
Sensor Active Area | 4608 × 2592 |
Frame Rate | 4608×2592@10fps, 2304×1296/1920×1080/1600×1200/1280×720@30fps |
Focus Type | Fixed Focus |
FOV | 75°(D)x66°(H)x41°(V) |
Lens Mount | Stock Lens |
Default Focus Distance | 1.5m -∞ |
F.NO | F1.8 |
Focal Length | 4.74mm |
IR Sensitivity | Integral IR-cut Filter, visible light only |
Interface | USB2.0 Device |
Adapter Board Size | 24mm x 25mm |
UVC Compliant | No additional drivers is required |
Operating Voltage | DC 5V +/- 5% |
Working Current | Max 300mA |
Operating Temp. | -4℉-158℉(-20°C to 70°C) |
Camera Board Size | 24mmx25mm |
Audio | Single Microphone |
Supported OS | Windows, Linux, Android and MAC |
Sample Application | Amcap-Windows Camera application for Video and Still Capture |
UVC Controls | Brightness, Contrast, Hue, Saturation, Sharpness, Gamma, White Balance, Gain, Exposure, Focus |
ARDUCAM相機模塊B0304產品介紹
目前大多數嵌入式攝像頭采用的MIPI CSI接口雖然速度快、穩定，但兼容性和便捷性遠不及兼容UVC協議的USB接口。而且在MIPI CSI接口的前提下，很多平臺使用攝像頭需要配套的驅動和軟件，比如樹莓派上的libcamera，Ubuntu上的V4L驅動等。
在樹莓派HQ攝像頭上適配UVC轉接板，通過該轉接板實現UVC協議的支持和通信。IMX708 UVC攝像頭也是如此，對其進行了適配，這樣就可以將其用作網絡攝像頭。
該攝像頭配備75°(D)x66°(H)x41°(V)定焦鏡頭和板載音頻。它兼容Windows、Linux、Android和MAC等。除了設備驅動程序之外，不需要安裝任何其他驅動程序，這是一款真正方便的攝像頭。
特點
? 兼容所有平臺：采用 UVC 協議，兼容各種平臺和操作系統，如 Windows、Linux、Mac、Android 等。
? 即插即用：只需安裝 USB 設備驅動程序，無需根據平臺添加其他驅動程序。安裝完成后即可即插即用。
? 高質量圖像：基于 SONY 12MP IMX708 圖像傳感器。最大分辨率：4608×2592。高分辨率可在更遠的距離獲得更清晰、更可識別的圖像。
? 定焦：配備 66°（HFOV）定焦鏡頭。與自動對焦鏡頭相比，定焦鏡頭對焦速度更快，圖像質量更穩定。
? 音頻功能：為這款 USB 攝像頭套件配備了支持高質量音頻輸入/輸出的麥克風模塊。
At present, the MIPI CSI interface used by most embedded cameras is high-speed and stable, but the compatibility and convenience are far less than the USB interface compatible with the UVC protocol. And under the premise of MIPI CSI interface, many platform to use the camera needs supporting drivers and software, such as libcamera on the Raspberry Pi, V4L driver on Ubuntu, etc.
The first attempt was to adapt the UVC adapter board on the Raspberry Pi HQ Camera, through which the UVC protocol support and communication can be realized. The same is true for the IMX708 UVC camera, which we adapted so you can use it as a webcam.
The camera is equipped with a 75°(D)x66°(H)x41°(V) Fixed Focus Lens and On-Board Audio. It is compatible with Windows, Linux, Android and MAC and so on. You don’t need to install any additional drivers other than the device driver, which is a truly convenient camera.
Features
? Compatible with All Platforms: Adopting UVC protocol, compatible with various platforms and operating systems, such as Windows, Linux, Mac, Android, etc.
? Plug and Play: Only the USB device driver needs to be installed, no additional drivers are needed depending on the platform. Just plug-and-play after the installation is completed.
? High-Quality Images: Based on SONY 12MP IMX708 Image Sensor. Max Resolution: 4608×2592. The high resolution allows you to get sharper and more recognizable images at a greater distance.
? Fixed Focus: Equipped with a 66°(HFOV) Fixed Focus Lens. Compared with the Autofocus Lens, the Fixed Focus Lens has a faster-focusing speed and more stable image quality.
? Audio Function: We have equipped this USB camera kit with a microphone module that supports High-Quality audio input/output.
