NEXON壓力變送器PA1500系列技術參數
Specifications | |
Supply voltage | |
Current output type | 10…30Vdc |
Current consumption | |
2line | Same as the output signal current(4…20mA) |
Current analog output | |
Output type | 2Wire4...20mA |
LoadRA(Ω) | RA(Us-10)V/0.02A |
Linearity | ≤±0.25%Range |
Voltage type analog output | |
Output type | 3Wire0...5V |
LoadRA(Ω) | RA≥5 |
Linearity | ≤±0.25%Range |
Accuracy | ≤±0.5%fs |
Stability (annual drift) | ≤±0.2%Range |
Temperature | |
Medium temperature | -40…+125℃ |
Ambient temperature | -20…+85℃ |
Material | |
Case | 304Stainless steel |
Media contact part | 304Stainless steel |
Degree of protection | 67(M12×1Connector) |
Outgoing way | M12×1Connector |
Process connection | G1/4external threadEDseal\M20×1.5external thread |
NEXON壓力變送器PA1500系列介紹
PA1500系列采用濺射膜技術，專為液壓機械和工程機械設計。全金屬外殼、耐液壓沖擊、溫度范圍廣，使該系列可用于各種惡劣的工作場景。提供多種輸出類型和連接，以滿足特定的安裝需求。
? 全不銹鋼結構緊湊直徑22mm
? 測量范圍從0…2000bar
? 高抗震性
? 2線4...20mA輸出
? 精度高達0.5%FS
? 工作溫度范圍-40-125℃
PA1500 series adopts sputtering film technology, specially designed for hydraulic machinery and construction machinery. Full metal casing, hydraulic shock resistance, and wide temperature range enable the series to be used in a variety of harsh work scenarios. A variety of output types and connections are available to meet specific installation needs.
? All stainless steel structure compact diameter 22mm
? Measuring range from 0…2000bar
? High shock reslstance
? 2-wire 4...20mA output
? High accuracy up to 0.5%FS
? Operating temperature range -40-125℃
NEXON壓力變送器PA1500系列其他常用型號：
NEXON PA1500/B600P0242G14MS
NEXON PA1500/B1000P0242G14MS
NEXON PA1500/B2000P0242G14MS
NEXON PA1500/B025P0305G14MS
NEXON PA1500/B040P0305G14MS
NEXON PA1500/B060P0305G14MS
NEXON PA1500/B100P0305G14MS
NEXON PA1500/B160P0305G14MS
NEXON PA1500/B250P0305G14MS
NEXON PA1500/B400P0305G14MS
NEXON PA1500/B600P0305G14MS
NEXON PA1500/B1000P0305G14MS
NEXON PA1500/B2000P0305G14MS
NEXON PA1500/B800P0242G14MM
