HENGESBACH液位探頭LEVELTEC S_SBC技術參數
Code | LEVELTEC S_SBC |
LEVELTEC Type | S |
Design | SB - Standard version |
Electrical connection | C - M16x1.5 cable screw connection |
HENGESBACH液位探頭LEVELTEC S系列介紹
標準 S 型液位探頭 Leveltec 產品系列用于液位監測和非導電介質的干運行保護。 電容式測量方法在不斷變化的介質中也具有廣泛的應用范圍。 電磁波穿透介質，電磁波的傳播時間會受到介電常數 ε 的影響。 未檢測到結皮、泡沫和冷凝物。
輸出信號可以直接連接到SPS或PLS進行處理。 通過正確選擇焊接部件和前板組件以確保在衛生方面適應該工藝。 可以采用用于振動叉的插座。 由于耐清潔溫度，可以執行滅菌和 CIP 清潔循環。
特征
液體液位檢測、泵保護、干運行保護、空/滿指示
在衛生方面采用不同過程連接的安裝
恒定開關點，無需任何對準
直接連接到 SPS 或 PLS
未檢測到泡沫和汗水
通過開關條件參數化，即使在粘性介質中也能可靠運行
The product family of level probes Leveltec of the types Standard S is used for level monitoring and for dry run protection with non conductive media. The capacitive measuring method allows a wide application range also with changing media. An electromagnetic wave penetrates the media and depending on the dielectric constant ε the propagation time of the electromagnetic wave is influenced. Crusts, foam and condensate are not detected.
The output signal can be connected directly to a SPS or PLS for processing. The adaption to the process with respect of hygienic aspects is asured by a proper selection of the welding parts and front flat assembly to the process. The adoption of sockets for vibrating forks is possible. Due to the resistance against cleaning temperatures sterilisations and CIP cleaning cycles are executable.
Features
level detection in fluids, pump protection, protection against dry run, empty / full indication
installation with different process connections with respect of hygienic aspects
constant switch-point without any alignment
direct connection to SPS or PLS
foam and perspiration water are not detected
reliable operation even in adhesive media by parameterization of both on and off condition
HENGESBACH液位探頭LEVELTEC系列選型
HENGESBACH液位探頭LEVELTEC系列其他常用型號：
HENGESBACH LEVELTEC L_SBCA
HENGESBACH LEVELTEC LR_SBMA
HENGESBACH LEVELTEC S_SBC
