PFANNENBERG揚聲器23310630000產品參數
PRODUCT | PA 1 |
DATA | |
Operating range | 10-57 V DC |
Nominal current consumption1 (max) | 80 mA |
Sound pressure level | 105 dB(A) |
Sound pressure level @DIN-tone | 104 dB(A) |
Sound level reduction | max. –12 dB via potentiometer |
Alarm tones | 80 thereof 4 tones are externally selectable |
Operating temperature | –40 °C ... +55 °C |
Storage temperature | –40 °C ... +70 °C |
Relative humidity | 90% |
Protection system according to EN 6052 | IP 66 (EN 60529), NEMA Type 4 & 4x |
Protection class | II |
Duty cycle | 100% |
Material | PC / ABS blend similar to RAL 3000 (flame red) | RAL 7035 (light grey) | RAL 9003 (signal white) |
Cable entry | 3x M20 knock-outs on side, 1 knock-out on back |
Integrated seal with cable entry | 7-13 mm (Feed-through grommet) |
Connecting terminals | 0.14 - 2.5mm簡 fine stranded / AWG24 - AWG 14 |
Weight | 270 g |
PFANNENBERG揚聲器其他常見型號：
PFANNENBERG 23310630000
PFANNENBERG 23310630001
PFANNENBERG 23310630055
PFANNENBERG 23310630056
PFANNENBERG speaker NEW + ORIGINAL+ ONE YEAR WARRANTY
