Sounder:

Maximum output:

112dB(A) @ 1 metre [103dB(A) @ 10ft/3m]

Nominal output:

105dB(A) @ 1m +/- 3dB – Tone 2 [96dB(A) @ 10ft/3m]

No. of tones:

32 (UKOOA / PFEER compliant)

No. of stages:

3

Volume control:

Max. 105dB(A); Min. 96dB(A) – Tone 2

Effective range:

60m/197ft @ 1KHz

Stage switching:

Negative – Reverse polarity stage switching on DC units.

Beacon:

Energy:

5 Joules (5Ws)

Flash rate:

1Hz (60 fpm)

Peak Candela:

500,000 cd – calculated from energy (J)

Effective Intensity:

250 cd – calculated from energy (J)

Peak Candela:

86,935 cd* – measured ref. to I.E.S.

Effective Intensity:

200 cd* – measured ref. to I.E.S.

Lens colours:

Amber, Blue, Clear, Green, Magenta, Red & Yellow

Tube life:

Emissions are reduced to 70% after 5 million flashes

General:

Voltages DC:

24V dc (10-30V dc); 48V dc (35-60V dc)
[DC units can use 24V ac for single stage applications.]

Voltages AC:

24V ac; 115V ac; 230V ac

Ingress protection:

IP66

Enclosure material:

High impact UL94 V0 & 5VA FR ABS

Colour:

Red (RAL3000), grey (RAL7038) & white.

Cable entries:

2 x M20 clearance gland entries in side & back

Terminals:

0.5 to 1.5mm2 cables.

Operating temp:

-25 to +55°C [-13° to +131°F]

Storage temp:

-40 to +70°C [-40° to +158°F]

Relative humidity:

90% at 20°C [68°F]

Weight:

DC: 0.95kg/2.1Ibs AC:1.20kg/2.64Ibs

*Candela measurements representative of performance with clear lens at optimum voltage.

*SPL data +/-3dB(A). Measured at optimum voltage.
