Conductivity

4 measuring ranges

Quadropole electrode

Range:

0 to 30.00 mS/cm

Cell constant:

typical 0,54 1/cm

Accuracy:

0 to 199 uS/cm ± 0.6 uS/cm
200 to 1999 uS/cm ± 6 uS/cm
2 to 11.99 mS/cm ± 0.06 mS/cm
12 to 15.99 mS/cm ± 0.03 mS/cm
16 to 30 mS/cm ± 0.06 mS/cm

Temperature

Sensor integrated in the conductivity electrode

Range:

0...100 °C

Resolution:

0.01 °C

Accuracy:

± 0.1 °C

Pressure

Reading selectable as mmHg, kPa, Bar or PSI

Version HDM97BQ and BO

Range:

-700 to + 1900 mmHg, 2 Bar

Resolution:

0.1 mmHg

Accuracy:

0 ... 300 mmHg ± 1 mmHg
otherwise ± 2 mmHg
in temperature range 20 to 23 °C
Ceramic sensor fluid resistant

Option H with higher accuracy

Range:

-700 to + 1900 mmHg, 2 Bar

Resolution:

0.01 mmHg

Accuracy:

0 ... 300 mmHg ± 0.5 mmHg,
1000 ... 1900 mmHg ± 2 mmHg
otherwise ± 1 mmHg
in temperature range 20 to 23 °C
Sensor not fluid resistent

Flow

Only Version BQ

Range:

100 ... 2000 ml/min

Resolution:

1 ml/min

Accuracy:

± 2 % from reading

Power Supply

Li-Ion-Polymer battery, rechargeable with 5 V DC, 500 mA

External charger:

Input Voltage

100 … 245 V / 50/60 Hz

Output Voltage

5 V DC, 500 mA

Or via USB-Interface from a computer

Operates up to 200 hours with fully charged battery

Dimensions and Weight

165 x 82 x 33 mm - 6.5" x 3.2" x 1.3”
0.4 Kg - 0.88 lbs including probe
