Technical data | |
Rated Supply Voltage Us | AC/DC 24-240 V, 0/45...65 Hz, < 5 VA DC: 20,4...297 V, AC: 20,4...264 V |
Relay output | 1 change-over contact (CO) |
Measuring inputs | 12 x Pt100 (RTD) according to EN 60 751 / IEC 60 751 |
Measuring time sensor | 0,25...3s (depending on number of sensors) |
Measuring range | -199°...850°C |
Resolution | 1°C |
Tolerance | ± 0,5% of value ± 1 K |
Sensor-current | ≤ 0,8 mA |
RS 485 interface | |
Adress of device | 0...96 |
Baud rate | 4800, 9600, 19200 baud |
Parity | N, O, E (non, odd, even) |
cable-length | max. 1000 m at 19200 baud |
Rated ambient temperature range | -20°C...+65°C |
Housing | Design V8 |
Dimensions (w x h x d) | 140 x 90 x 58 mm, mounting height 55 mm |
Protection housing/terminals | IP 30 / IP 20 |
Attachment | DIN-rail 35 mm acc. to EN 60715 or screws M4 |
Gewicht | ca. 350 g |
ZIEHL溫度繼電器T224095產品介紹
用于傳感器的12通道溫度繼電器Pt100（RTD）
溫度繼電器TR1200可在199 ... + 850°C范圍內測量多達12個傳感器的溫度，并在RS485接口處提供數據以進行外部評估。通過其通用電源AC / DC 24-240 V，它可以連接到所有公共電源電壓。
TR1200提供Modbus-RTU協議數據或ZIEHL標準數據。使用ZIEHL協議標準，它可以取代2個ZIEHL TR600繼電器。
TR1200用于許多傳感器Pt100的溫度應由帶輸入RS485的設備進行評估。
應用于監控
電動機和發電機（繞組，軸承，冷卻液，環境溫度）
變壓器（繞組，鐵芯，環境溫度）
機器，設備和設備
傳感器和顯示器
12個輸入傳感器Pt 100（RTD）
連接2線或3線
可以關閉不需要的輸入
監測傳感器以短路中斷
電子數字顯示溫度
LED用于分配測量值，錯誤，繼電器和接口狀態
接口：
接口RS485（協議ZIEHL標準和modbus RTU）
波特率（4800/9600/19200）和奇偶校驗位
可選協議請參見www.ziehl.de上的操作手冊
傳感器錯誤和操作失敗的錯誤繼電器（1份共同合同）
更多功能
易于操作和選擇設備溫度
傳感器仿真
防止設置操作的代碼保護
通用電源電壓AC / DC 24 ... 240 V.
開關柜安裝外殼，140 mm寬，安裝高度55 mm
安裝在DIN導軌上35 mm或使用M4螺釘（可選）
操作軟件（從www.ziehl.de下載）
用于編程輸入的軟件
記錄功能（僅限連接的PC）
每個TR1200的硬件：帶USB或RS232接口的PC + RS485-USB或RS485-RS232轉換器（取決于接口）
軟件：Win7 / Win10，Excel 2010-2016
12-channel Temperature-Relay for Sensors Pt100 (RTD)
Temperature relays TR1200 measure the temperature of up to 12 sensors within 199...+850°C and provide the data at an interface RS485 for external evaluation. With its universal power-supply AC/DC 24-240 V it can be connected to all common supply voltages.
The TR1200 provides the data as Modbus-RTU-protocol or according to the ZIEHL-standard. With protocol ZIEHL standard it can replace 2 ZIEHL TR600 relays.
The TR1200 is used where temperatures of many sensors Pt100 shall be evaluated by a device with input RS485.
Applications are e.g. monitoring of
motors and generators (windings, bearings, coolant, ambient temperature)
transformers (windings, core, ambient temperature)
machines, plants and equen
Sensors and Displays
12 inputs for sensors Pt 100 (RTD)
Connection 2- or 3-wire
unneeded inputs can be switched off
monitoring of sensors for short-circuit an interrupt
e-digit-display for temperature
LEDs for assigning the measured value, error, state of relay and interface
Interfaces:
Interface RS485(protocols ZIEHL standard and modbus RTU)
Baud rate (4800/9600/19200) and Parity-Bit
selectable protocols see operating manual on www.ziehl.de
Relay for error (1 co-contract) for sensor error and operational failure
More features
easy operation and selection of temperatures at the device
Sensor-Simulation
Code protection against manipulation of settings
Universal supply voltage AC/DC 24…240 V
Housing for switchgear-mount, 140 mm wide, mounting height 55 mm
mounting on DIN rail 35 mm or with screws M4 (option)
Software for operation(download from www.ziehl.de)
software (modbus) for programming the inputs
Logging function (with connected PC only)
Hardware for every TR1200: PC with USB or RS232 interface + RS485-USB or RS485-RS232 converter (depending on interface)
Software: Win7 / Win10, Excel 2010-2016
