Number of electrical poles:

4

Class efficiency 1:

China Energy Label, Grade 2

Operating mode:

S1

P2 power (KW):

4.0

Ambient temperature min. ℃:

-20

Circuit 1:

D

Circuit 2:

Y

Frequency 1-2 (Hz):

50

Special version:

suitable for zone 1 or 21

Flange / size:

FF215, oil protected

KLK position SEW:

270 ° / normal

Type of balancing:

semi-keli balancing

Ventilation:

Electrically conductive fan

Braking torque (NM):

51

Engine type:

CD

Motor type 4 pol .:

M-4

Variant:

SMN_2

Efficiency class 1:

IE3 Premium Efficiency

Thermal class 1:

F to B

Ambient temperature max. ℃:

40

Speed 1 (1 / min):

1500

Voltage 1 (V):

230

Voltage 2 (V):

400

Activation / motor start:

direct

Design:

B5

Cable entry:

Version 1

Protection class IP:

66

Pinion DMR unit shaft (mm):

18 mm

Brake:

ATB, CM112

Brake voltage (V):

400

Hand release:

yes

Temperature class / Expl. Protection:

T4

Expl. Protection Gsa other:

Ex de IIC T3 ... T6 Gb

Painting:

only primed 1K

Bes. Feature U:

but CCC certification

Bes. Feature W:

3 cable entries

Directive:

2014/34 / EU
