MAGMOTOR 有刷電機C33系列產品參數
Product Category | DC Motors |
Performance Specifications | |
DC Voltage | 12.0 to 120.0 VDC |
Shaft Speed | 4000 rpm |
Continuous Current | 7.3 amps |
Continuous Torque | 10.75 In-lbs (12.4 kg-cm) |
Output Power | 0.2412 HP |
Torque Constant | 15.2 in-oz/amp (107 mN-m/amp) |
Rotor Inertia | 0.0400 oz-in-sec2 (0.2825 kg-cm2) |
Motor Type | |
DC Construction | Permanent Magnet |
Commutation | Brush |
Shaft Orientation | In-line; Single-ended |
Gearing Options | |
Gearing | Motor Only (No Gearhead) |
Housing / Enclosure | |
Units | English |
Motor Shape | Cylindrical Body |
Diameter / Width | 3.25 inch (83 mm) |
Length | 6.32 inch (161 mm) |
NEMA Frame | 34 |
Other Specifications | |
Feedback | Integral Encoder (optional feature); Integral Tachometer (optional feature) |
Features | Servomotor; Brake (optional feature) |
Environment | |
Operating Temperature | 311 F (155 C) |
Environment | Totally Enclosed |
MAGMOTOR有刷電機C33系列產品介紹
流暢的四極性能
傾斜平衡電樞
編碼器就緒
圓形或可選NEMA 34安裝
12-120 Vdc可用
Smooth 4-Pole Performance
Skewed and Balanced Armatures
Encoder Ready
Round or Optional NEMA 34 Mounting
12-120 VDC Available
MAGMOTOR 有刷電機C33系列
愛澤工業(IZE INDUSTRIES)特價經銷、常用備件MAGMOTOR 有刷電機部分型號：
MAGMOTOR C33-C-400
MAGMOTOR C33-D-200
MAGMOTOR C33-E-100
MAGMOTOR C33-E-300
MAGMOTOR C33-E-400
MAGMOTOR C33-F-200
MAGMOTOR C33-G-100
MAGMOTOR C33-G-300
MAGMOTOR C33-H-400
MAGMOTOR C33-I-200
MAGMOTOR C33-I-300
MAGMOTOR C33-J-100
MAGMOTOR C33-J-400
MAGMOTOR C33-K-200
MAGMOTOR C33-K-300
MAGMOTOR C33-L-100
MAGMOTOR DC Motors NEW + ORIGINAL+ ONE YEAR WARRANTY
