Introduction to SEW Motor K Series
Due to its long-term maintenance-free service life and wear-free transmission, SEW's spiral bevel gear unit is technically an economical right-angle gear unit. However, their high efficiency makes them a true energy saver.
K series helical bevel gear reducer with high efficiency and gear transmission, high fatigue strength
The compact design of all SEW gearboxes is most evident in spiral bevel gear units. For example, this property is especially interesting for machine applications with limited space available. Here you need powerful drive technology and a compact design. For SEW's spiral bevel gear reducers, the torque range is from 80 to 50,000 Nm, which is a suitable environment.
These right-angle gearboxes are highly efficient in terms of direction of rotation and any input speed and are therefore very energy efficient. Their high-endurance transmissions are wear-free and continue to use the gearbox. For precision positioning tasks, you can use a K-Series reducer that reduces backlash.
In the SEW product portfolio: dimensions K..39 and K..49 complete the two-stage spiral bevel gear reducer series. They set the standard with the K..19 and K..29 dimensions: four sizes allow torque from 80 Nm to 500 Nm.
Combine the K-series gearbox and AC motor to the K..DR.. spiral bevel gear motor or combine the servo motor to your chosen K..CMP spiral bevel gear servo motor with the modular concept of SEW . Or simply choose a separate AC or servo motor that meets your requirements.
application:
? Pallet conveyor
? Belt conveyor
? Chain conveyor
? Lifts and lifting stations
? Scissor lift
? Freight elevator
? Stroke and crane drive in the stacker
SEW motor K series technical information
K series / size 37/47/57/67/77/87/97/107/127/157/167/187 (three stages)
Gear ratio （i）3.98 - 197.37
Double gear reduction ratio（i）94 - 32 625
maximum. Output torque（Nm）200 - 50 000
Motor power range (installed via AM motor adapter)（KW）0.12 - 90
K series / size 19 / 29/39 / 49 (two levels)
K..19 K..29 K..39 K..49
Gear ratio（i） 4.50 - 58.68 3.19 -71.93 2.81 - 58.24 4.0 - 75.20
maximum. Output torque（Nm）80 130 300 500
Motor power range (installed via AM motor adapter)（KW）0.12 -1.1 0.12 - 2.2 0.12 - 4.0 0.12 - 7.5
SEW motor K series advantages
Helical bevel gear reducer (two and three)
? High efficiency
? Gears have high fatigue strength
? Long service life, maintenance free
? Can be combined with SEW's complete motor combination
Size K..37 to K..187 (three stages)
? Dual gear unit also provides very small output speed
? Reduce backlash variants
? Available variants:
- foot or flange mounting
-B5 or B14 flange mounting
- solid shaft or hollow shaft
- Hollow shaft key connection, locking disc, splined hollow shaft, or TorqLOC ?
Sizes K..19, K..29 and K..39, K..49 (two stages)
? Low loss, two-stage design, high transmission efficiency over 90%
? Aluminum housings of size K..19 and K..29 make it particularly lightweight
? Due to the gray cast iron casing, the dimensions K..39 and K..49 are particularly strong and torsionally rigid
? Three base strips ensure optimal connection to the client machine even in critical installation situations
? Available variants:
- Foot or B5 flange mounting
- solid shaft or hollow shaft
- Hollow shaft with key connection or shrink disk or Torq LOC? hollow shaft mounting system
SEW motor K series
IZE INDUSTRIES special distribution, common spare parts SEW motor series list:
SEWmotor K37,K47,K57,K67,K77,K87,K97,K107,K127,K157,K167,K187
SEWmotor KS37,KS47,KS57,KS67,KS77,KS87,KS97,KS107,KS127,KS157,KS167,KS187
SEWmotor KA37,KA47,KA57,KA67,KA77,KA87,KA97,KA107,KA127KA157,KA167,KA187
SEWmotor KF37,KF47,KF57,KF67,KF77,KF87,KF97,KF107,KF127,KF157,KF167,KF187
SEWmotor KAF37,KAF47,KAF57,KAF67,KAF77,KAF87,KAF97,KAF107,KAF127,KAF157,KAF167,KAF187
SEWmotor KAT37,KAT47,KAT57,KAT67,KAT77KAT87,KAT97,KAT107,KAT127,KAT157,KAT167,KAT187,KAZ37,KAZ47
SEWmotor KAZ57,KAZ67,KAZ77,KAZ87,KAZ97,KAZ107,KAZ127,KAZ157,KAZ167,KAZ187
Who we are
IZE-industries was established in 2010.With its many years of professional experience, providing advanced manufacturing industries technology and equipment. Including advanced electrical automation, machinery and transmission, fluid control, instrumentation, tools and other products. As a partner in electrical, hydraulic and pneumatic solutions, we also provide our customers with consulting solutions, market knowledge, and value-added services.
What we offer
Engineering and Consulting
Full-service controls engineering and consulting solutions for industrial
manufacturing equipment, including:
Electrical design
PLC programming and repair
Process optimization
Down-time consultation
spare parts from the areas, including:
Hydraulic, Pneumatic, Industrial, Automation technology.
Please contact us for complete stock list or special discount.
If you have any question for K series of SEW motors, please feel free to dial 0086-21-3100 6702 or browse our website: jjxdch.cn.
For more detailed information on the K series of SEW motors or to purchase SEW related products, please contact IZE Industries.
