Introduction to SEW Motor F Series
The shaft parallel gear unit has a slim design. With a high torque rating of 130 Nm to 18,000 Nm, it delivers outstanding performance in many conveying and machining applications. Suitable for limited space. The design and torque perfectly match the limited installation space.
The F series is one of the best gearboxes. Even in difficult installation conditions, various mounting positions and variations enable a wide range of applications without sacrificing performance.
You can choose the foot, flange or shaft mounting options. For precise positioning tasks, SEW's parallel-axis helical gear reducers reduce backlash.
Use the modular concept of SEW to combine the F series gearbox and AC motor to the F..DR .. parallel shaft geared motor, or combine the servo motor to your choice of F..CMP parallel axis helical servo motor. Or simply choose a separate AC or servo motor that meets your requirements.
SEW motor F series technical information
Gear unit ratio (i) 3.77 - 281.71
Double gear reduction ratio (i) 87 - 31 434
maximum. Output torque (Nm) 130 - 18 000
Motor power range (installed via AM motor adapter) (kW) 0.12 – 200
application:
Conveyor application
Chain conveyor
Process application
Press
Extruder
Screw conveyor
Gantry crane
SEW motor F series advantages
Ultra-thin design, limited installation space, low space requirements
Can also reduce backlash
Benefit from 11 sizes (27 to 157) and multiple models to meet different requirements
Output torque from 200 Nm to 18,000 Nm even in reduced clearance designs
Available variants:
Foot or flange mounting
B5 or B14 flange mounting
Solid shaft or hollow shaft
Hollow shaft with key connection, shrink disk, splined hollow shaft or TorqLOC?
SEW Encoder F Series
IZE INDUSTRIES special distribution, common spare parts SEW encoder series list:
SEWmotor F：
F27，F(xiàn)37，F(xiàn)47，F(xiàn)57，F(xiàn)67，F(xiàn)77，F(xiàn)87，F(xiàn)97，F(xiàn)107，F(xiàn)127，F(xiàn)157
SEWmotor FA：
FA27，F(xiàn)A37，F(xiàn)A47，F(xiàn)A57，F(xiàn)A67，F(xiàn)A77，F(xiàn)A87，F(xiàn)A97，F(xiàn)A107，F(xiàn)A127，F(xiàn)A157
SEWmotor FF：
FF27，F(xiàn)F37，F(xiàn)F47，F(xiàn)F57，F(xiàn)F67，F(xiàn)F77，F(xiàn)F87，F(xiàn)F97，F(xiàn)F107，F(xiàn)F127，F(xiàn)F157
SEWmotor FV：
FV27，F(xiàn)V37，F(xiàn)V47，F(xiàn)V57，F(xiàn)V67，F(xiàn)V77，F(xiàn)V87，F(xiàn)V97，F(xiàn)V107，F(xiàn)V127，F(xiàn)V157
SEWmotor FHF：
FHF27，F(xiàn)HF37，F(xiàn)HF47，F(xiàn)HF57，F(xiàn)HF67，F(xiàn)HF77，F(xiàn)HF87，F(xiàn)HF97，F(xiàn)HF107，F(xiàn)HF127，F(xiàn)HF157
SEWmotor FVF：
FVF27，F(xiàn)VF37，F(xiàn)VF47，F(xiàn)VF57，F(xiàn)VF67，F(xiàn)VF77，F(xiàn)VF87，F(xiàn)VF97，F(xiàn)VF107，F(xiàn)VF127，F(xiàn)VF157
SEWmotor FAF：
FAF27，F(xiàn)AF37，F(xiàn)AF47，F(xiàn)AF57，F(xiàn)AF67，F(xiàn)AF77，F(xiàn)AF87，F(xiàn)AF97，F(xiàn)AF107，F(xiàn)AF127，F(xiàn)AF157
SEWmotor FA-B：
FA27B，F(xiàn)A37B，F(xiàn)A47B，F(xiàn)A57B，F(xiàn)A67B，F(xiàn)A77B，F(xiàn)A87B，F(xiàn)A97B，F(xiàn)A107B，F(xiàn)A127B，F(xiàn)A157B
SEWmotor FH-B：
FH27B，F(xiàn)H37B，F(xiàn)H47B，F(xiàn)H57B，F(xiàn)H67B，F(xiàn)H77B，F(xiàn)H87B，F(xiàn)H97B，F(xiàn)H107B，F(xiàn)H127B，F(xiàn)H157B
SEWmotor FV-B：
FV27B，F(xiàn)V37B，F(xiàn)V47B，F(xiàn)V57B，F(xiàn)V67B，F(xiàn)V77B，F(xiàn)V87B，F(xiàn)V97B，F(xiàn)V107B，F(xiàn)V127B，F(xiàn)V157B
