SUN閥RPGD-ABN技術參數
Technical Data | |
Cavity | T-3A |
Series | 2 |
Capacity | 50 gpm |
Maximum Operating Pressure | 2000 psi |
Pilot Ratio | 0.834027778 |
Maximum Valve Leakage at 110 SUS (24 cSt) | 3 in3/min.@1000 psi |
Maximum Air Pressure | 150 psi |
Response Time - Typical | 10 ms |
Valve Hex Size | 1 1/8 in. |
Valve Installation Torque | 45 - 50 lbf ft |
Model Weight | 0.53 lb. |
Seal kit - Cartridge | Buna: 990203007 |
Seal kit - Cartridge | Polyurethane: 990003002 |
Seal kit - Cartridge | Viton: 990203006 |
SUN閥RPGD-ABN產品介紹
空氣控制、先導式、平衡活塞減壓閥芯使用隔膜上的壓縮空氣而不是可調節彈簧來控制壓力設置。 空氣信號通過盒六角端的端口提供。 它們是常閉壓力調節閥。 當入口（端口 1）處的壓力達到閥門設定值時，閥門開始向油箱（端口 2）打開，節流流量以調節壓力。 這些閥門準確，壓力上升與流量較低，平穩安靜，速度適中。
? 所有2 端口泄壓閥芯（先導泄壓閥除外）在物理和功能上均可互換（對于給定的框架尺寸，具有相同的流路、相同的腔體）。
? 端口2 可接受最大壓力； 適用于跨端口泄壓電路。
? 最大氣壓不應超過150 psi (10 bar)。
? 采用Sun 浮動式結構，最大限度地減少由于安裝扭矩過大和/或型腔/盒加工變化而導致內部零件粘連的可能性。
Air-controlled, pilot-operated, balanced piston relief cartridges use compressed air over a diaphragm instead of an adjustable spring to control pressure setting. The air signal is supplied through a port in the hex-end of the cartridge. They are normally closed pressure regulating valves. When the pressure at the inlet (port 1) reaches the valve setting, the valve starts to open to tank (port 2), throttling flow to regulate the pressure. These valves are accurate, have low pressure rise vs. flow, they are smooth and quiet, and are moderately fast.
? All 2-port relief cartridges (except pilot reliefs) are physically and functionally interchangeable (same flow path, same cavity for a given frame size).
? Will accept maximum pressure at port 2; suitable for use in cross port relief circuits.
? Maximum air pressure should not exceed 150 psi (10 bar).
? Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.
SUN閥RPGD系列其他常用型號：
SUN RPGD-ABN
SUN RPGD-ABV
SUN RPGD-AIN
SUN RPGD-AIV
SUN RPID-BBN
SUN RPKD-BBN
SUN RQEB-LAN
SUN RQGB-LAN
SUN RQIB-LAN
SUN RQKB-LAN
