BUSAK+SHAMBAN斯特封RSK300900-T46產品參數
Specification | |
Rod dN f8/h9 | 90.0 |
Groove Diameter D1 h9 | 105.1 |
Groove Width L1 +0.2 | 6.3 |
O-Ring Size | 94.62 x 5.33 |
BUSAK+SHAMBAN斯特封RSK300900-T46產品介紹
在所有操作條件下，桿密封不得向大氣側出現動態泄漏，并且當機器處于靜止?fàn)顟B(tài)時，桿密封必須靜態完全密封。
此外，它們應通過低摩擦實現高機械效率，并且易于安裝在小凹槽中。成本和使用壽命必須滿足運營商的高期望。
桿密封Turcon Stepseal 2K最接近于滿足這些理想要求。自1972年第一個Stepseal獲得專利并投放市場以來，Trelleborg密封解決方案通過不斷創新的設計和Turcon和Zurcon材料的進一步發展，將該系列保持為技術上杰出的密封元件。Turcon Stepseal 2K延續了傳統的改進。
隨著階梯密封的引入，第一次有可能安排幾個密封，一個接一個，從而允許靜態和動態緊雙作用串聯密封配置，而不會干擾中間壓力的積累。單作用密封元件由優質Turcon或Zurcon材料制成，具有優異的滑動和耐磨性能。根據ISO 7425/2和Trelleborg密封溶液標準槽安裝，使用O型環作為通電元件。
Rod seals must exhibit no dynamic leakage to the atmosphere side under all operating conditions and must be statically completely leak tight when the machine is at a standstill.
Furthermore, they should achieve a high degree of mechanical efficiency through low friction and be easy to install in small grooves. Costs and service life must meet the high expectations of the operator.
The rod seal Turcon Stepseal 2K comes closest to satisfying these ideal demands. Since the first Stepseal was patented and introduced to the market in 1972,Trelleborg Sealing Solutions has maintained the series as technically outstanding seal elements through continuous innovative further development of the design and of the Turcon and Zurcon materials. Turcon Stepseal 2K continues the tradition for improvement.
With the introduction of Stepseal it was possible for the first time to arrange several seals, one behind the other,thus allowing statically and dynamically tight doubleacting tandem seal configurations to be created, without any disturbing build-up of intermediate pressure. The single-acting seal element is made of high-grade Turcon or Zurcon materials with outstanding sliding and wear resistance properties. It is installed according to ISO 7425/2 and Trelleborg Sealing Solutions standard grooves, using an O-Ring as energizing element.
選型參考
BUSAK+SHAMBAN斯特封RSK系列其他常見型號：
BUSAK+SHAMBAN RSK300825
BUSAK+SHAMBAN RSK200830
BUSAK+SHAMBAN RSK200850
BUSAK+SHAMBAN RSK300850
BUSAK+SHAMBAN RSK400850
BUSAK+SHAMBAN RSK300890
BUSAK+SHAMBAN RSK200900
BUSAK+SHAMBAN RSK300900
BUSAK+SHAMBAN RSK400900
BUSAK+SHAMBAN RSK200920
BUSAK+SHAMBAN RSK300920
BUSAK+SHAMBAN RSK200950
