Source pressure                  AP 1200

vacuum to 1,700 psig (117 bar)

AP 1200 HF

vacuum to 1,700 psig (117 bar)

AP 1200 FC

 vacuum to 300 psig (21 bar)

AP 1200 HR

vacuum to 3,000 psig (207 bar)

Delivery pressure                 AP 1202

1 to 30 psig (0.07 to 2 bar) (not available for FC or HR)

AP 1206

1 to 60 psig (0.07 to 4 bar) (not available for FC or HR)

AP 1210

2 to 100 psig (0.14 to 7 bar)

AP 1215?

5 to 150 psig (.34 to 10 bar)

AP 1225

Preset to 250 psig (17 bar) at 800 psig inlet
Custom inlet/outlet pressure settings available. Contact factory. (not available for FC)

Proof pressure

150% of operating pressures

Burst pressure

300% of operating pressures

Other Parameters

Inlet/outlet connectors

1/4, 3/8, 1/2, 3/4 inch face seal or tube weld

Bonnet port

1/8 inch NPT

Flow coefficient (Cv)

0.9 (HF = 1.1 and FC = 0.65)

Internal volume

1.07 in3 (17.6 cm3)

Operating temperature

-40° to +160°F (-40° to +71°C)*

Surface finish

15 μin Ra max / 10 μin. Ra avg.
(0.4/0.25 μm) standard; 10 μin (0.25 μm);
7 μin (0.18 μm); and 5 μin (0.13 μm) Ra max optional

Inboard leakage

2 x 10-10 sccs

Outboard leakage

2 x 10-9 sccs He

Leakage across seat

4 x 10-8 sccs He

Installation

surface or panel (optional)

Supply pressure effect
HF & FC

3.5 psig per 100 psig source pressure change
4.2 psig per 100 psig source pressure change
