Weight

0.15 kg (0.33 lbs)

Installation   orientation

Unrestricted

Storage ambient   temperature range

-40 to 100 °C (-40 to   212 °F)

Operating ambient   temperature range

-30 to 90°C (-22 to   194°F) for W=0000
  -30 to 75°C (-22 to 167°F) for W=000T

Salt spray test to DIN   EN ISO 9227:2017-07

500h

Hydraulic

Max. operating   pressure

350 bar (5000 psi)

Flow range

0.5 - 40 l/min. (0.1 -   11 gpm) for W=0000
  0.5 - 30 l/min. (0.1 - 8 gpm) for W=000T

Fatigue cycle life

2 million cycles at   350 bar
  150000 cycles at 420 bar

Max. internal leakage:

5 drops/min. for X=   01,05,07
  20 drops/min. for X= 31,03,09

Switching time for   W=0000

Opening ≤ 50 ms
  Closing ≤ 100 ms

Switching time for   W=000T

Opening ≤ 50 ms
  Closing ≤ 50 ms

Fluid temperature   range

-20 to 80 °C (-4 to   176 °F)

Fluids: Mineral-based   or synthetics with lubricating properties at viscosities of 20 to 380 mm2/s   (cSt)

Installation torque

35 - 43 Nm (26 - 32   ft-lbs)

Recommended degree of fluid   contamination

Nominal value max. 10   μm (NAS 8) ISO 4406 19/17/14

Cavity

CA-08A-2N

Seal kit for   X=01,05,07

code RG08A2010520100
  material no. R901101437

Seal kit for   X=31,03,09

code RG08A2010530100
  material no. R901101544

Seal kit coil and standard   cap

code RG02Z0010000100
  material no. R930067869

Seal kit coil and   protective cap only for Y=D

code RG03Z0010000100
  material no. R930067870

Electrical

Type of voltage

DC voltage

Coil type

D36

Power consumption

20 W
