RETSCH電磁振動篩AS300 control技術參數
Applications | separation, fractioning, particle size determination |
Field of application | agriculture, biology, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals |
Feed material | powders, bulk materials, suspensions |
Measuring range | 20 μm - 40 mm |
Sieving motion | throwing motion with angular momentum |
Max. batch / feed capacity | 6 kg |
Max. number of fractions | 11/17 |
Max. mass of sieve stack | 10 kg |
Amplitude | digital, 0.2 - > 2.20 mm |
Controlled amplitude | yes |
Sieve acceleration | 1.0 - > 10.0 g |
Time display | digital, 1 - 99 min |
Interval operation | 1 - 99 s |
Storable SOPs | 99 |
Suitable for dry sieving | yes |
Suitable for wet sieving | yes |
Serial interface | yes |
Including test certificate / can be calibrated | yes |
Suitable sieve diameters | 100 mm / 200 mm / 203 mm (8") / 305 mm / 315 mm |
Max. height of sieve stack | 510 mm |
Clamping devices | "standard", "comfort", each for wet and dry sieving |
Protection code | IP 54 / IP 20 |
Electrical supply data | 100-240 V, 50/60 Hz |
Power connection | 1-phase |
W x H x D | 417 x 220 x 384 mm |
Net weight | ~ 42 kg |
Standards | CE |
RETSCH電磁振動篩AS300 control產品介紹
分析振動篩AS 300 control用于研發、原材料、中間產品和成品的質量控制以及生產監控。可控的電磁驅動為每一種產品提供了最佳的適應性。即使在很短的篩分時間后也能獲得尖銳的部分。
AS 300 control專為直徑為305 mm (12")的測試篩而設計。與直徑為200 mm的篩相比，篩面高出2.25倍。因此，平均篩分時間可以大大減少與AS 300控制。
應用示例
水泥熟料、化學品、咖啡、建筑材料、肥料、填料、面粉、谷物、金屬粉末、礦物質、堅果、塑料、沙子、種子、土壤、洗衣粉……
The analytical sieve shaker AS 300 control is used in research & development, quality control of raw materials, interim and finished products as well as in production monitoring. The controllable electromagnetic drive offers an optimal adaption for every product. Sharp fractions are obtained even after short sieving times.
The AS 300 control is particularly designed for test sieves with a diameter of 305 mm (12"). Compared to sieves with a diameter of 200 mm, a 2.25 times higher sieving surface is available. Therefore, the average sieving times can be greatly reduced with the AS 300 control.
APPLICATION EXAMPLES
cement clinker, chemicals, coffee, construction materials, fertilizers, fillers, flours, grains, metals powders, minerals, nuts, plastics, sand, seeds, soils, washing powder, ...
