美國DYNAPAR微型編碼器M9-0100-2.0-1 M90100/002.01尺寸圖及選型參數表
美國DYNAPAR微型編碼器M9-0100-2.0-1 M90100/002.01特性描述
ELECTRICAL
Supply Voltage: 5 VDC ±10%
Supply Current: 10 mA, typ.
Output Signals: 2.5 V min. high (VOH);
0.5 V max. low (VOL). 6 mA sink/source (25°C),
4 mA (100°C)
Frequency Response: 200 kHz
Termination: 5 pin header (accessory 12” wires
w/connector, part no. CA0050012) or flying leads
Recommended Mating Connector: AMP part
number 103675-4
MECHANICAL
Hub Diameter: 1.5, 2.0, 2.5, 3.0, 4.0 mm;
0.125, 0.156 inch
Mounting Configuration: Modular Hollow Bore
Mount
Hub Dia. Tolerance: +0.0004”/-0.0000”
(+0.010 mm/-0.000 mm)
Mating Shaft Length: See table (page 2)
Mating Shaft Runout: 0.001 TIR
Mating Shaft Endplay: >256 ppr: ±0.003”
(±0.076mm); 250, 256 ppr: +0.005/-0.003”
(+0.127/-0.076mm); <250 ppr: +0.007/-0.003”
(+0.178/-0.076mm)
Moment of Inertia: 0.15 x 10-5 oz-in-sec2
(0.11 gm-cm2
)
Housing and Cover: Plastic
Weight: 0.15 oz (4.14 g)
ENVIRONMENTAL
Operating Temperature: -20° to 100°C
Storage Temperature: -50° to 125°C
Humidity: Up to 90% (non-condensing)
美國DYNAPAR微型編碼器M9-0100-2.0-1 M90100/002.01等常用型號匯總
愛澤工業(IZE INDUSTRIES)特價經銷、常用備件型號：
DYNAPAR微型編碼器M90100/003.01
DYNAPAR微型編碼器E9S-E0-0100-00-3.0-1-D
DYNAPAR微型編碼器M90100/0A1251
DYNAPAR微型編碼器E9S-E0-0100-01-125-A-D
DYNAPAR微型編碼器M90100/0A1252
DYNAPAR微型編碼器M90100/0A2.02
DYNAPAR微型編碼器M90100/0A3.01
DYNAPAR微型編碼器E9S-E0-0100-01-3.0-A-D
DYNAPAR微型編碼器M90100/0A3.02
DYNAPAR微型編碼器E9S-E0-0100-02-3.0-A
DYNAPAR微型編碼器M90100/0A4.01
DYNAPAR微型編碼器E9S-0100-04-0-1-A
DYNAPAR微型編碼器M90100/0C1252
DYNAPAR微型編碼器E9S-E0-0100-02-125-C-D
DYNAPAR微型編碼器M90100/0C1561
DYNAPAR微型編碼器E9S-E0-0100-01-156-C
DYNAPAR微型編碼器M90100/0C2.01
DYNAPAR微型編碼器E9S-E0-0100-01-2.0-A-D
DYNAPAR微型編碼器M90100/0D4.02
DYNAPAR微型編碼器E9S-E0-0100-XX-XXX-X-D
DYNAPAR微型編碼器M90100/0E1562
DYNAPAR微型編碼器E9S-E0-0100-XX-XXX-X-D
DYNAPAR微型編碼器M90100/0E3.01
DYNAPAR微型編碼器E9S-E0-0100-01-3.0-E-D
DYNAPAR微型編碼器M90144/0A2.51
DYNAPAR微型編碼器M90200/004.01
DYNAPAR微型編碼器E9S-E0-0200-01-4.0-D
DYNAPAR微型編碼器M90200/0C1561
DYNAPAR微型編碼器E9S-E0-0200-01-156-C
DYNAPAR微型編碼器M90200/0D1251
DYNAPAR微型編碼器E9S-E0-0200-01-125-D
DYNAPAR微型編碼器M90200/0D1561
DYNAPAR微型編碼器E9S-E0-0200-01-156-D
DYNAPAR微型編碼器M90200/0D4.01
DYNAPAR微型編碼器E9S-E0-0200-01-4.0-D-D
DYNAPAR微型編碼器M90256/001251
DYNAPAR微型編碼器M90256/0A2.01
DYNAPAR微型編碼器E9S-E0-0256-01-2.0-A-D
DYNAPAR微型編碼器M90256/0A2.5204
DYNAPAR微型編碼器M90256/0A3.0204
DYNAPAR微型編碼器M90256/0E1562
DYNAPAR微型編碼器E9S-E0-0256-02-156-C-D
DYNAPAR微型編碼器M90300/0C1561
DYNAPAR微型編碼器E9S-E0-0300-01-156-D
DYNAPAR微型編碼器M90300/0C1562
DYNAPAR微型編碼器E9S-E0-0300-01-156-D
DYNAPAR微型編碼器M90360/0A4.02
DYNAPAR微型編碼器E9S-E0-0360-0A-4.0-2
DYNAPAR微型編碼器M90500/002.51
DYNAPAR微型編碼器E9S-E0-0500-02-.51
DYNAPAR微型編碼器M90500/0A1251
DYNAPAR微型編碼器E9S-E0-0500-01-125-A
DYNAPAR微型編碼器M90500/0A2.01
DYNAPAR微型編碼器E9S-E0-0500-01-2.0-A-D
DYNAPAR微型編碼器M90500/0A2.02
DYNAPAR微型編碼器E9S-E0-0500-02-2.0-A-D
DYNAPAR微型編碼器M90500/0A3.01
DYNAPAR微型編碼器E9S-E0-0500-01-3.0-A-D
DYNAPAR微型編碼器M90500/0A3.0204
DYNAPAR微型編碼器M90500/0A4.01
DYNAPAR微型編碼器E9S-E0-0500-01-4.0-A
DYNAPAR微型編碼器M90500/0C1252
DYNAPAR微型編碼器E9S-E0-0500-02-125-C-D
DYNAPAR微型編碼器M90500/0C1561
DYNAPAR微型編碼器E9S-E0-0500-01-156-C-D
DYNAPAR微型編碼器M90500/0C1872
DYNAPAR微型編碼器E9S-E0-0500-02-187-C
DYNAPAR微型編碼器M90512/001.52
DYNAPAR微型編碼器E9S-E0-0512-00-1.5-2-D
DYNAPAR微型編碼器M90512/004.01
DYNAPAR微型編碼器E9S-E0-0512-01-4.0-D
DYNAPAR微型編碼器M90512/0A1.52
DYNAPAR微型編碼器E9S-E0-0512-0A-1.5-2-D
DYNAPAR微型編碼器M90512/0A1251
DYNAPAR微型編碼器E9S-E0-0512-01-125-A-D
DYNAPAR微型編碼器M90512/0A1252
DYNAPAR微型編碼器E9S-E0-0512-02-125-A-D
DYNAPAR微型編碼器M90512/0A3.01
DYNAPAR微型編碼器E9S-E0-0512-01-3.0-A-D
DYNAPAR微型編碼器M90512/0A4.01
DYNAPAR微型編碼器M90512/0C1252
DYNAPAR微型編碼器E9S-E0-0512-02-125-C-D
DYNAPAR微型編碼器M90512/0C2.02
DYNAPAR微型編碼器M90512/0C4.01
愛澤工業專業提供美國DYNAPAR微型編碼器M9-0100-2.0-1 M90100/002.01等，美國DANAHER集團旗下全系列產品，DYNAPAR重載微型編碼器，HENGSTLER微型編碼器/NORTHSTAR（北極星）HSD351024PA4，HSD351024PA7微型編碼器等等。
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的首選渠道。
如果有任何關于美國DYNAPAR微型編碼器M9-0100-2.0-1 M90100/002.01的疑問，請隨時與我們聯系，（021-3100 6702），我們將盡全力解決您的問題。
If you have any question, please feel free to dial 0086-21-3100 6702 or browse our website:jjxdch.cn.
美國DYNAPAR微型編碼器M9-0100-2.0-1 M90100/002.01尺寸圖及選型參數表
