BUSCH-JAEGER電位器2117 U技術參數
Technical | |
Compatible Bus Systems: | DALI |
Design: | Busch-Rotary-Dimmer |
Design Range: | 63x63 |
Actuator Type: | Turn/push button |
Mounting Type: | Flush Mounted |
Application Function: | Electrical Load and Light Control |
Environmental | |
Ambient Air Temperature: | Operation 0 ... +35 °C |
Degree of Protection: | IP20 |
Dimensions | |
Product Net Width: | 71 mm |
Product Net Height: | 71 mm |
Product Net Depth / Length: | 51 mm |
Product Net Weight: | 96 g |
Built-In Depth (t2): | 28.5 mm |
BUSCH-JAEGER電位器2117 U產品介紹
用于 DALI 廣播服務（通過中央電報）。用于切換和調光多達 64 個 DALI 設備，例如帶 DALI 接口的電子鎮流器和變壓器。具有旋轉控制和ON/OFF推動操作。開機亮度和背景亮度可調，緩沖。具有用于定向的集成 LED 照明。方向燈顏色可調（18 個預設和關閉）。可并聯多達 5 個電位器。電流消耗：MAX. 15mA。不適合與其他 DALI 傳感器或其他制造商的中央單元組合。需要額外的 DALI 電源，例如 Tridonic、Philips、Helvar 或 2117/11 U。DALI 電纜長度：300 m (1.5 - 2.5 mm2)。不帶蓋板。
For DALI broadcast service (via central telegram). For switching and dimming up to 64 DALI- devices like electronic ballasts and transformers with DALI-interface. With rotary control and ON/OFF push operation. Fool proved. Brightness power-on level and backround brightness level adjustable, buffered. With integrated LED illumination for orientation. Color of orientation light adjustable (18 presets and OFF). Up to 5 potentiometers are connectable in parallel. Max. current consumption: 15 mA. Not suitable for combining with other DALI sensors or central units of other manufacturers. An additional DALI power supply is needed, e.g. by Tridonic, Philips, Helvar or 2117/11 U. Max. DALI-cable length: 300 m (1,5 - 2,5 mm2). Without cover plate.
BUSCH-JAEGER電位器其他常用型號：
BUSCH-JAEGER 2025 RFID U
BUSCH-JAEGER 2051 U
BUSCH-JAEGER 2052 U
BUSCH-JAEGER 2053 U
BUSCH-JAEGER 2058 UK
BUSCH-JAEGER 2112 U-101
BUSCH-JAEGER 2116 U
BUSCH-JAEGER 2116/11 U
BUSCH-JAEGER 2117 U
BUSCH-JAEGER 2117/11 U
BUSCH-JAEGER POTENTIOMETER NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于BUSCH-JAEGER電位器2117 U的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for BUSCH-JAEGER products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:jjxdch.cn.
