愛澤工業2023年3月部分到貨產品專題及庫存
——REGO，GENERANT泄壓閥篇
如下為我司愛澤工業IZE_Industries本月到貨REGO和GENERANT相關產品，歡迎致電索取樣本資料和產品信息。
REGO閥3125L
GENERANT閥VRV125B-T-10
GENERANT閥VRV125B-T-15
應用
專為保護可能會截留液態液化石油氣或無水氨的管道和截止閥而設計。 它們可以安裝在位于截止閥之間或 RegO 截止閥的側凸臺中的管道和軟管中。
特征
? 泄壓閥設計為在排放后自動重新固定牢固。
? 彈性閥座圓盤提供“無氣泡”密封。
? 有黃銅和不銹鋼兩種材質可供選擇。
? 可提供在需要時允許直接連接排氣管道的配置。
Application
Designed especially for the protection of piping and shut-off valves where there is a possibility of trapping liquid LP-Gas or anhydrous ammonia. They may be installed in pipelines and hoses located between shut-off valves or in the side boss of RegO shut-off valves.
Features
? Relief valve designed to automatically reseat firmly after discharge.
? Resilient seat disc provides a “bubble-tight” seal.
? Available in both brass and stainless steel.
? Available in configurations that permit direct attachment of vent piping when required.
一種緊湊、高精度、直接作用的泄壓閥。 出廠預設為所需的開啟壓力和/或流量規格。 內部調節提供防篡改安全性，防止無意的壓力變化。 可用黃銅、鋁和 316 不銹鋼制成的通向大氣或內聯配置的通風口。 閥門采用四環密封件，可通過狹窄的重新密封帶提供極高的精度和可重復性。 可選的偏轉蓋增加流量并提供排放偏轉。
A compact, highly accurate, direct acting pressure relief valve. Factory preset to desired crack pressure and/or flow specifications. Internal adjustment provides tamper proof safety against inadvertent pressure changes. Available vent to atmosphere or inline configurations in brass, aluminum and 316 stainless steel. Valves feature a Quad ring seal which provides for extreme accuracy and repeatability with a narrow reseal band. Optional deflector cap increases flow capacity and provides for deflection of discharge.
Generant 系列不銹鋼 CRV 低溫安全閥是一種彈簧參考過壓保護裝置。不銹鋼 CRV 提供清潔和包裝用于氧氣服務，使其成為大多數低溫安全閥應用的理想選擇。可訂購設定壓力范圍為 10 至 750 PSIG（0.69 至 51.7 巴）的閥門，出廠預設并永久鎖定。不能在現場改變或調整釋放壓力。閥座和提升閥幾何形狀與優化的彈簧范圍相結合，可提供高流量和最小的壓力積累。緊湊的設計和各種入口和出口配置的可用性降低了尺寸和管道要求。釋放壓力可以排放到大氣中或排放到下游連接。 CRV 可以指定為設定壓力高于 50 PSIG (3.45Bar) 的 PCTFE 或 PTFE，指定壓力低于 50 PSIG 的氟硅橡膠，以及整個可用設定壓力范圍內的 FKM (Viton?)。
特征
? 提供 NPT、金屬對金屬面密封和 Bi-Lok 雙卡套管連接
? 高流量和出色的再密封性能
? 排放到大氣或各種內嵌管道配置
? 提供工廠預設并永久鎖定以提供防篡改服務
? 100% 的泄漏、開裂和重新密封性能經過工廠測試
? 可選的導流帽可用于轉移廢氣
? 針對氧氣服務進行清潔和包裝
The Generant Series Stainless Steel CRV, Cryogenic Relief Valve is a spring reference over pressure protection device. The Stainless CRV is supplied cleaned and packaged for oxygen service making it an ideal choice for most cryogenic relief valve applications. The valve can be ordered with set pressures ranging from 10 to 750 PSIG (0.69 to 51.7 Bar) and come factory preset and permanently locked. Relief pressure cannot be altered or adjusted in the field. Seat and poppet geometry combined with optimized spring ranges provide high flow rates with minimum pressure accumulation. Compact design and availability of a variety of inlet and outlet configurations reduces size and piping requirements. Relief pressure can be discharged to atmosphere or to a downstream connection. The CRV can be specified with PCTFE or PTFE for set pressures above 50 PSIG (3.45Bar), Fluorosilicone for set pressures below 50 PSIG, and FKM (Viton?) throughout the available set pressure range.
Features
? Available in NPT, Metal to Metal Face Seal and Bi-Lok Dual Ferrule Tube Connections
? High Flow Capacity and Excellent Reseal Performance
? Discharge to Atmosphere or a Wide Varity of Inline Piping Configurations
? Supplied Factory Preset Set and Permanently Locked for Tamper Proof Service
? 100% Factory Tested for Leakage, Crack and Reseal Performance
? Optional Deflector Cap available for diverting exhausted gas
? Cleaned and Packaged for Oxygen Service
REGO / GENERANT閥常用型號：
REGO 3127K
REGO 3129K
REGO 3125L
REGO 3127L
REGO 3129L
REGO SS8001L
REGO SS8002L
REGO SS8021L
REGO SS8022L
REGO 3127U
REGO 3129U
GENERANT VRV125B-T-10
GENERANT VRV125B-T-15
GENERANT VRV250B-T-10
GENERANT VRV375B-T-10
GENERANT VRV500B-T-10
GENERANT VRV750B-T-10
GENERANT VRV1000B-T-10
GENERANT CRV8-8-K-203
GENERANT CRV8-8-K-348
GENERANT CRV8-8-K-131
GENERANT CRV8-8-K-740
如果您需要完整的REGO和GENERANT的相關技術咨詢，請隨時致電愛澤工業（021-3100 6702），或者訪問網站jjxdch.cn,我們將盡全力解決您的問題。
If you have any question for REGO or GENERANT，please feel free to dial 0086-21-3100 6702 or browse our website: jjxdch.cn.
