SEVERN磁導率計產品介紹
SEVERN磁導率計介紹
低微量元素滲透率指示器是一種簡單，堅固，無損的檢測儀器，專為實驗室，車間和現場使用而開發。GO，NO-GO功能允許對奧氏體不銹鋼和錳鋼基體和焊接材料進行即時驗收測試。該指標不需要任何外部標準，不需要任何調整，不需要任何視覺讀數，并且不受位置的影響。它在片材，板，棒，不規則形狀的物體以及復雜組件的單個零件上的性能同樣出色。它可以有效地定位異質產品中的高滲透率或低滲透率區域，并可以用于需要冷成形和退火操作的場合。
The Low Mu Permeability Indicator is a simple, rugged, non-destructive inspection instrument developed for laboratory, shop and field use. The GO, NO-GO feature permits instant acceptance testing of austenitic stainless and Manganese steel base and weld materials. The Indicator requires no external standards, no adjustments, no visual readings and is unaffected by position. It performs equally well on sheets, plates, rods, irregular shaped objects and individual parts of complex components. It is effective in locating areas of high or low permeability in heterogeneous products and has application where cold forming and annealing operations are required.
描述
指示器重3盎司。5英寸長，適合手持操作。所有金屬組件均鍍鎳。指示器及其插入物裝在一個漂亮的木盒子里。該指示器符合SEV-ENG-96001（MIL-I-17214B的替代規格）。
Description
The Indicator weighs 3 oz. and is 5 inches long making it comfortable for hand held operations. All metal components are bright Nickel plated. The Indicator and it’s Inserts are furnished in a handsome wooden box. The Indicator conforms to SEV-ENG-96001, the replacement specification for MIL-I-17214B.
SEVERN磁導率計使用說明
高靈敏度低微量元素滲透率指示器是一種易于操作的設備，用于指示低滲透率材料的相對滲透率。
指示器的操作基于用于校準插入件和未知材料的永久磁鐵的相互吸引。在使用中，將插入件擰入殼體的頂部。然后通過取決于刀片的磁導率的力將磁體吸引到插入件上。從殼體底部的開口伸出的磁鐵末端然后與被測材料接觸。接觸面必須清潔且無氧化皮或異物，然后將指示劑沿垂直于接觸面的方向移開。如果被測材料的磁導率高于校準插件的磁導率，則當指示器移開時，磁鐵將與插件底部完全分離。當固定磁鐵的金屬軸環撞擊塑料外殼的底部時，將發生完全分離。如果被測材料的磁導率低于插入值，則當指示器移開時，磁鐵將首先與被測材料分離。因此，通過互換插入物，可以確定兩個插入物的值之間的材料的滲透性。該指標并未確定材料滲透率的單一準確值；它確定了滲透率范圍，每個刀片的公差極限在校準證書的背面指定。
指標的兩個功能值得特別提及。首先，附有磁鐵的平衡梁允許在所有位置使用指示器，而無需進行重力校正。其次，半球形磁體末端與插入件和測試材料提供點接觸。
The High Sensitivity Low-mu Permeability Indicator is a simple-to-operate device to be used for indicating the relative permeability of low permeability materials.
The operation of the Indicator is based on the mutual attraction of a permanent bar magnet for a calibrated insert and an unknown material. In use, an insert is screwed into the top of the case. The magnet is then atracted to the insert by a force dependent upon the insert's permeability. The end of the magnet projecting from the opening in the bottom of the case is then brought into contact with the material being tested. It is essential that the contact surface be clean and free from oxide scale or foreign material.The Indicator is then moved away in a direction perpendicular to the contact surface. If the material being tested has a higher permeability than that of the calibrated insert, then the magnet will completely separate from the bottom of the insert as the Indicator is moved away. A complete separation occurs when the metal collar holding the magnet strikes the bottom of the plastic case. If the permeability of the material being tested is lower than that of the insert value, the magnet will first separate from the test material as the Indicator is moved away. Thus, by interchanging the inserts, it is possible to determine the permeability of the material betweenthe values of two inserts. The Indicator does not determine a single exact value for the permeability of the material; it determines a permeability range, The tolerance limits for each insert is specified on the back of the Certificate of Calibration.
Two features of the Indicator deserve special mention. First, the balanced beam to which the magnet is attached permits the use of the Indicator in all positions without correction due to gravity. Secondly, the hemispherical magnet ends provide point contact with the inserts and the test materials.
SEVERN可選插入值
SEVERN 1.01Mu
SEVERN 1.02Mu
SEVERN 1.03Mu
SEVERN 1.04Mu
SEVERN 1.05Mu
SEVERN 1.06Mu
SEVERN 1.08Mu
SEVERN 1.09Mu
SEVERN 1.10Mu
SEVERN 1.15Mu
SEVERN 1.20Mu
SEVERN 1.30Mu
SEVERN 1.40Mu
SEVERN 1.50Mu
SEVERN 1.60Mu
SEVERN 1.80Mu
SEVERN 1.90Mu
SEVERN 2.00Mu
SEVERN 2.20Mu
SEVERN 2.50Mu
SEVERN 3.00Mu
SEVERN 3.50Mu
SEVERN 4.00Mu
SEVERN 4.50Mu
SEVERN 5.00Mu
SEVERN 5.50Mu
SEVERN 6.00Mu
如果您有任何關于SEVERN的相關技術咨詢或者需要產品的相關技術資料與文檔，請隨時致電愛澤工業（021-3100 6702），或者訪問網站jjxdch.cn,我們將盡全力解決您的問題。
If you have any question for SEVERN，please feel free to dial 0086-21-3100 6702 or browse our website: jjxdch.cn.
