TESTRON門速儀MAA37245S操作手冊（簡易版）
TESTRON門速儀MAA37245S 愛澤工業ize-industries
特征
1.電池供電
2.上電后處于測試速度模式
3.雙向讀取速度
4.5個可調節的HI/LO速度極限曲線，適用于過速情況
5.菜單自定義限制和定時器
6.可調傳感器斷電計時器
7.可調顯示/超速斷電計時器
8.可調速度計電源關閉定時器
9.能夠標準化速度計算以適應傳感器變化。
Features
1. Battery operate d
2. Powers up in Test Velocity mode
3. Reads velocity in both directions
4. 5 Adjustable HI/LO Velocity limit Profiles for Overspeed
5. Menu for customizing limits and timers
6. Adjustable Sensor Power Down Timer
7. Adjustable Display/Overspeed Power Down Timer
8. Adjustable Velocity Meter Power Down Timer
9. Ability to normalize velocity calculation for sensor variation.
操作方式
將測速儀放在所需的位置以測量速度。按CE/C按鈕打開設備電源。裝置已準備好測試速度。傳感器電源關閉計時器到期后，傳感器將斷電，如果按任意鍵，則將重新通電。在“顯示器關閉電源”計時器到期后，顯示器將關閉電源，如果按任意鍵，則將重新打開電源。電源關閉計時器到期后，測速儀將關閉電源。任何按鍵或速度讀數都將重置關機定時器。如果測速儀正在等待另一個傳感器，則傳感器和顯示器將保持打開狀態，直到關閉電源計時器到期為止。
當測速器啟動時，它默認為選定的配置文件。
Operation
Place the Velocity Meter in the desired position to measure velocity. Press the CE/C button to power the unit on. The unit is now ready for testing velocity. The Sensors will power off after the Sensor Power Off timer has expired and will power back on if any key is pressed. The Display will power off after the Display Power Off timer has expired and will power back on if any key is pressed. And the Velocity Meter will power off after the Power Off timer has expired. Any key press or velocity reading will reset the Power Off timers. If the Velocity Meter is waiting for the other sensor the Sensors and Display will remain on until the Power Off timer has expired.
When the Velocity Meter powers up, it defaults to the selected profile.
操作流程
開始測試
使用菜單
選擇配置文件
修改配置文件
修改傳感器關閉時間
修改顯示時間
修改斷電時間
查看工具編號和修訂級別
查看歸一化因子
使用檢查夾具和一些理論
Operating procedures
Starting a test
Using the Menus
Selecting Profile
Modify Profile
Modify SENSOR OFF TIME
Modify DISPLAY OFF TIME
Modify POWER OFF TIME
Viewing the Tool Number and Revision Levels
Viewing the Normalization Factor
Using the check fixture and a little theory
如果您需要完整的TESTRON門速儀MAA37245S的操作手冊或者相關技術咨詢，請隨時致電愛澤工業（021-3100 6702），或者訪問網站jjxdch.cn,我們將盡全力解決您的問題。
If you have any question for TESTRON，please feel free to dial 0086-21-3100 6702 or browse our website: jjxdch.cn.
